VSH SudoPress Carbon elbow 90° (press x male)

group: SP8001VM

The VSH SudoPress SP8001V is a 90° elbow with a press and a tube end. By using VSH SudoPress in your piping installation you can install in a quick, easy and clean way. VSH SudoPress provides a piping system that can be used in the most diverse situations.

  • Leak Before Pressed function
  • provided with all relevant approvals
  • clear identification on fitting of material and dimension
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

heating

heating

cooling

cooling

compressed air

compressed air

solar energy

solar energy

vacuum

vacuum

segments

commercial building

commercial building

industry

industry

approvals

no approvals available

item number

size

d1

DN1

l1

z1

d2

DN2

l2

radius

angle

item number

6562292

size

66.7xØ66.7

d1

66.7

DN1

DN65

l1

145

z1

95

d2

66.7

DN2

DN65

l2

157

radius

80

angle

90

item number

6562303

size

76.1xØ76.1

d1

76.1

DN1

DN65

l1

155

z1

100

d2

76.1

DN2

DN65

l2

168

radius

92

angle

90

item number

6562314

size

88.9xØ88.9

d1

88.9

DN1

DN80

l1

179

z1

116

d2

88.9

DN2

DN80

l2

193

radius

107

angle

90

item number

6562325

size

108xØ108

d1

108.0

DN1

DN100

l1

216

z1

139

d2

108.0

DN2

DN100

l2

233

radius

130

angle

90

technical drawing for product

characteristics

color

silver

materials

steel (St 34.2 (1.0034))

finishing

galvanised

manufacturer

Aalberts integrated piping systems B.V. (VSH)

shape

Bend (90º)

connection type

press (M), tube end

sealing

EPDM

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

73079980

brand

VSH

series

SudoPress Carbon

type

SP8001VM

UNSPS

40172802

label

value

label

Material connection 1

value

Steel

label

Material quality connection 1

value

St 34.2 (1.0034)

label

Surface protection connection 1

value

Galvanic/electrolytic zinc plated

label

Material connection 2

value

Steel

label

Material quality connection 2

value

St 34.2 (1.0034)

label

Surface protection connection 2

value

Galvanic/electrolytic zinc plated

label

Shape

value

Bend

label

Model

value

1-part

label

Bend angle

value

90°

label

Reducing

value

No

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Press sleeve

label

Contour code connection 1

value

M

label

Connection 2

value

Soldered end

label

Main colour fitting

value

Grey

label

Flange compression class (PN)

value

PN 16

label

Material sealing

value

Ethylene-propylene diene monomer rubber (EPDM)

label

With buffer stud

value

Yes

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-35°C - 135°C

label

Medium temperature (continuous) (imperial)

value

-31°F - 275°F

label

Max. operating pressure at 20 °C

value

16bar

label

Max. operating pressure at 20 °C (imperial)

value

232.06psi

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With drain valve

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No
