SP4330V
The VSH SudoPress SP4330V is a straight union connector with 2 press ends. The connection coupling makes it possible to combine robustness with the option of disconnecting part of the installation. By using VSH SudoPress in your piping installation you can install in a quick, easy and clean way. VSH SudoPress provides a piping system that can be used in the most diverse situations.
applications
solutions
approvals
item number | size | weight | dimensions | packaging | gtin |
---|---|---|---|---|---|
6672281 | 12 | 0.12 kg | 63x120x75 mm | bag (5 pce) | 03430651360654 |
6672292 | 15 | 0.16 kg | 69x30x30 mm | bag (5 pce) | 03430651360661 |
6672303 | 18 | 0.16 kg | 76x37x32 mm | bag (5 pce) | 03430651360678 |
6672314 | 22 | 0.22 kg | 73x40x40 mm | bag (5 pce) | 03430651360685 |
6672325 | 28 | 0.32 kg | 76x50x50 mm | bag (5 pce) | 03430651360692 |
6672336 | 35 | 0.4 kg | 83x55x55 mm | bag (1 pce) | 03430650360709 |
6672347 | 42 | 0.61 kg | 119x69x60 mm | bag (1 pce) | 03430650360716 |
6672358 | 54 | 0.95 kg | 114x90x90 mm | bag (1 pce) | 03430650360723 |
item number | size | d1 | DN1 | l1 | z1 | slw1 | d2 | DN2 | l2 | z2 | slw2 |
---|---|---|---|---|---|---|---|---|---|---|---|
6672281 | 12 | 12.0 | DN10 | 28 | 10 | 32 | 12.0 | DN10 | 35 | 17 | 24 |
6672292 | 15 | 15.0 | DN12 | 30 | 8 | 32 | 15.0 | DN12 | 39 | 17 | 24 |
6672303 | 18 | 18.0 | DN15 | 37 | 15 | 32 | 18.0 | DN15 | 39 | 17 | 27 |
6672314 | 22 | 22.0 | DN20 | 32 | 9 | 41 | 22.0 | DN20 | 41 | 18 | 30 |
6672325 | 28 | 28.0 | DN25 | 33 | 9 | 50 | 28.0 | DN25 | 43 | 19 | 38 |
6672336 | 35 | 35.0 | DN32 | 36 | 11 | 50 | 35.0 | DN32 | 47 | 22 | 46 |
6672347 | 42 | 42.0 | DN40 | 61 | 25 | 60 | 42.0 | DN40 | 58 | 22 | 50 |
6672358 | 54 | 54.0 | DN50 | 50 | 9 | 78 | 54.0 | DN50 | 64 | 23 | 72 |
color | bronze |
---|---|
materials | bronze, brass (CW617N, EN CC499K) |
finishing | none |
manufacturer | Aalberts integrated piping systems B.V. (VSH) |
shape | straight |
connection type | press (V) |
sealing | EPDM |
product group | fittings (union) |
---|---|
ETIM class | EC003024 Fitting with 2 connections |
HS code | 74122000 |
brand | VSH |
series | SudoPress Copper |
type | SP4330V |
UNSPS | 40174907 |
SCIP | 5cf0b298-027a-4aed-9537-63ab9cac8f2d |
SDS-VSH_SudoPress_Copper_brass-gunmetal link to sheet |
download | |
SP4330V image |
png | download |
SudoPress Copper DVGW Water certifications |
download | |
SudoPress Copper WRAS certifications |
download | |
SudoPress Koper KIWA certifications |
download | |
VSH SudoPress Copper 15-54mm RISE ENG certifications |
download | |
VSH SudoPress Copper Avis Technique certifications |
download | |
VSH SudoPress Copper-ACS certifications |
download | |
VSH SudoPress TSU certifications |
download | |
Diagram diagram |
png | download |
VSH SudoPress Copper 15-54mm RISE SE certifications |
download | |
VSH SudoPress instructions installation- & maintenance document |
download |
label | value |
---|---|
ETIM class | EC003024 Fitting with 2 connections |
Material connection 1 | Bronze |
Material quality connection 1 | CuSn5Zn5Pb2 |
Surface protection connection 1 | Untreated |
Surface treatment connection 1 | Untreated |
Material connection 2 | Brass |
Material quality connection 2 | CuZn40Pb2 (CW617N) |
Surface protection connection 2 | Untreated |
Surface treatment connection 2 | Untreated |
Shape | Straight |
Model | 3-part |
Reducing | No |
Eccentric | No |
System specific | Yes |
Connection 1 | Press sleeve |
Contour code connection 1 | V |
Connection 2 | Press sleeve |
Contour code connection 2 | V |
Main colour fitting | Bronze |
Flange compression class | PN 16 |
Material sealing | Ethylene-propylene diene monomer rubber (EPDM) |
With buffer stud | Yes |
High tensile strength | Yes |
Medium temperature (continuous) | -20°C - 110°C |
Medium temperature (continuous) (imperial) | -4°F - 230°F |
Max. operating pressure at 20 °C | 16bar |
Max. operating pressure at 20 °C (imperial) | 232.06psi |
With sealing rings/gaskets | Yes |
Capped | No |
With connection indicator | Yes |
With drain valve | No |
With de-aerator | No |
FM quality mark | No |
LPCB quality mark | No |
ULC quality mark | No |
UL quality mark | No |
VdS quality mark | No |
DVGW quality mark for gas | No |
DVGW quality mark for water | Yes |
Certified according to NF 545 | No |
KIWA certified | Yes |
Gastec QA mark | No |
KOMO certified | No |
item number | description | |
---|---|---|
6558508 | VSH SudoPress O-ring FPM LBP 12 | |
6569805 | VSH SudoPress O-ring EPDM LBP 12 | |
6211898 | Deburrer for carbon and stainless steel tube 12-54 | |
6580002 | Novopress jaw PB1 V12 | |
6580068 | Novopress jaw PB2 V12 | |
6558519 | VSH SudoPress O-ring FPM LBP 15 | |
6569816 | VSH SudoPress O-ring EPDM LBP 15 | |
6580013 | Novopress jaw PB1 V15 | |
6580079 | Novopress jaw PB2 V15 | |
6558521 | VSH SudoPress O-ring FPM LBP 18 | |
6569827 | VSH SudoPress O-ring EPDM LBP 18 | |
6580024 | Novopress jaw PB1 V18 | |
6580081 | Novopress jaw PB2 V18 | |
6558530 | VSH SudoPress O-ring FPM LBP 22 | |
6569838 | VSH SudoPress O-ring EPDM LBP 22 | |
6580035 | Novopress jaw PB1 V22 | |
6580090 | Novopress jaw PB2 V22 | |
6558541 | VSH SudoPress O-ring FPM LBP 28 | |
6569849 | VSH SudoPress O-ring EPDM LBP 28 | |
6580046 | Novopress jaw PB1 V28 | |
6580101 | Novopress jaw PB2 V28 | |
6558552 | VSH SudoPress O-ring FPM LBP 35 | |
6569851 | VSH SudoPress O-ring EPDM LBP 35 | |
6580112 | Novopress jaw PB2 V35 | |
6580057 | Novopress jaw PB1 V35 | |
6673425 | VSH SudoPress Copper O-ring FPM LBP 42 | |
6673348 | VSH SudoPress O-ring EPDM LBP 42 | |
6580123 | Novopress jaw PB2 V42 | |
6580156 | Novopress sling snap on V42 | |
6673427 | VSH SudoPress Copper O-ring FPM LBP 54 | |
6673359 | VSH SudoPress Copper O-ring EPDM LBP 54 | |
6580134 | Novopress jaw PB2 V54 | |
6580167 | Novopress sling snap on V54 |
