VSH XPress Copper straight connector (press x female thread)

group: 6270G

The VSH XPress 6270G is a straight connector made of gunmetal with a press and female thread end. By using VSH XPress in your piping installation you can install in a quick, easy and clean way. VSH XPress provides a complete piping system suitable for every conceivable application.

  • insert stop: stop edge for pipe end
  • provided with all relevant approvals
  • Leak Before Pressed-function
  • clear identification on fitting of material and dimension
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

potable water

potable water

heating

heating

cooling

cooling

compressed air

compressed air

vacuum

vacuum

segments

residential

residential

commercial building

commercial building

industry

industry

shipbuilding

shipbuilding

approvals

ATG

ATG

BSI Kitemark

BSI Kitemark

DNV-GL

DNV-GL

DVGW Wasser

DVGW Wasser

KIWA

KIWA

ÖVGW Wasser

ÖVGW Wasser

QB (CSTBat)

QB (CSTBat)

RISE

RISE

SINTEF

SINTEF

ÜA

ÜA

WRAS

WRAS

item number

size

d1

DN1

l1

z1

d2

DN2

l2

z2

slw2

item number

4801269

size

12xRp3/8"

d1

12.0

DN1

DN10

l1

17

z1

0

d2

17.2

DN2

3/8" (DN10)

l2

14

z2

6

slw2

20

item number

4801271

size

12xRp1/2"

d1

12.0

DN1

DN10

l1

18

z1

0

d2

21.3

DN2

1/2" (DN15)

l2

17

z2

8

slw2

22

item number

4801280

size

15xRp3/8"

d1

15.0

DN1

DN12

l1

20

z1

2

d2

17.2

DN2

3/8" (DN10)

l2

14

z2

6

slw2

20

item number

4801291

size

15xRp1/2"

d1

15.0

DN1

DN12

l1

20

z1

3

d2

21.3

DN2

1/2" (DN15)

l2

18

z2

8

slw2

25

item number

4801302

size

15xRp3/4"

d1

15.0

DN1

DN12

l1

21

z1

5

d2

26.9

DN2

3/4" (DN20)

l2

19

z2

8

slw2

30

item number

4801313

size

18xRp1/2"

d1

18.0

DN1

DN15

l1

19

z1

2

d2

21.3

DN2

1/2" (DN15)

l2

18

z2

8

slw2

25

item number

4801324

size

18xRp3/4"

d1

18.0

DN1

DN15

l1

20

z1

2

d2

26.9

DN2

3/4" (DN20)

l2

19

z2

9

slw2

30

item number

4801335

size

22xRp1/2"

d1

22.0

DN1

DN20

l1

20

z1

1

d2

21.3

DN2

1/2" (DN15)

l2

17

z2

7

slw2

30

item number

4801346

size

22xRp3/4"

d1

22.0

DN1

DN20

l1

20

z1

0

d2

26.9

DN2

3/4" (DN20)

l2

19

z2

9

slw2

30

item number

4801357

size

22xRp1"

d1

22.0

DN1

DN20

l1

21

z1

3

d2

33.7

DN2

1" (DN25)

l2

22

z2

11

slw2

37

item number

4801368

size

28xRp3/4"

d1

28.0

DN1

DN25

l1

23

z1

3

d2

26.9

DN2

3/4" (DN20)

l2

17

z2

7

slw2

37

item number

4801379

size

28xRp1"

d1

28.0

DN1

DN25

l1

23

z1

3

d2

33.7

DN2

1" (DN25)

l2

22

z2

10

slw2

37

item number

4801381

size

28xRp1 1/4"

d1

28.0

DN1

DN25

l1

24

z1

2

d2

42.4

DN2

1 1/4" (DN32)

l2

24

z2

10

slw2

46

item number

4805691

size

35xRp3/4"

d1

35.0

DN1

DN32

l1

29

z1

4

d2

26.9

DN2

3/4" (DN20)

l2

15

z2

4

slw2

30

item number

4801390

size

35xRp1"

d1

35.0

DN1

DN32

l1

24

z1

5

d2

33.7

DN2

1" (DN25)

l2

22

z2

10

slw2

42

item number

4806076

size

64xRp2 1/2"

d1

64.0

DN1

DN60

l1

49

z1

1

d2

76.1

DN2

2 1/2" (DN65)

l2

40

z2

9

slw2

82

item number

4801401

size

35xRp1 1/4"

d1

35.0

DN1

DN32

l1

25

z1

3

d2

42.4

DN2

1 1/4" (DN32)

l2

25

z2

11

slw2

46

item number

4801412

size

42xRp1 1/4"

d1

42.0

DN1

DN40

l1

30

z1

0

d2

42.4

DN2

1 1/4" (DN32)

l2

22

z2

8

slw2

46

item number

4801423

size

42xRp1 1/2"

d1

42.0

DN1

DN40

l1

29

z1

3

d2

48.3

DN2

1 1/2" (DN40)

l2

25

z2

11

slw2

48

item number

4801434

size

54xRp2"

d1

54.0

DN1

DN50

l1

34

z1

3

d2

60.3

DN2

2" (DN50)

l2

25

z2

11

slw2

48

technical drawing for product

characteristics

color

copper

materials

bronze (EN CC499K)

finishing

none

shape

straight, reducer

connection type

press (M), Rp - female thread cylindrical (BSPT)

sealing

EPDM

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

74122000

brand

VSH

series

XPress Copper

type

6270G

SCIP

966cd6bc-74ae-47a8-951b-016935a13ff8

technical

max operating pressure liquid

16 bar

min. medium temperature

-20 °C

max medium temperature

110 °C

peak medium temperature

135 °C

image for 6270G

image | png

6270G

image for Diagram

diagram | png

Diagram

installation- & maintenance document | pdf

VSH XPress installation instructions

link to sheet | pdf

MSDS_VSH_XPress_Copper

certifications | pdf

VSH XPress Copper RISE 12-108 mm SE

certifications | pdf

VSH_XPress_Copper_WRAS

certifications | pdf

XPress Copper BSI

certifications | pdf

XPress Copper DVGW Water

certifications | pdf

XPress Copper KIWA

certifications | pdf

XPress_Copper_ATG

certifications | pdf

XPress_Copper_QB

certifications | pdf

XPress_Copper_SINTEF

certifications | pdf

XPress_Copper_Water_OVGW

certifications | pdf

XPress_DNV

certifications | pdf

VSH XPress Copper RISE 12-108 mm EN

label

value

label

Material connection 1

value

Bronze

label

Material quality connection 1

value

CuSn5Zn5Pb2

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Bronze

label

Material quality connection 2

value

CuSn5Zn5Pb2

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Straight

label

Model

value

1-part

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Press sleeve

label

Contour code connection 1

value

M

label

Connection 2

value

Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)

label

Main colour fitting

value

Copper

label

Flange compression class (PN)

value

PN 16

label

Material sealing

value

Ethylene-propylene diene monomer rubber (EPDM)

label

With buffer stud

value

Yes

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-20°C - 110°C

label

Medium temperature (continuous) (imperial)

value

-4°F - 230°F

label

Max. operating pressure at 20 °C

value

16bar

label

Max. operating pressure at 20 °C (imperial)

value

232.06psi

label

With thermal insulation

value

No

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With drain valve

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

DIN-CERTCO certificate

value

No

label

VdS quality mark

value

No

label

With approval for TÜV

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

Yes

label

Certified according to NF 545

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No

label

Type approval according to BBR/EKS

value

No

item number

carbon footprint (A-C) embodied carbon

data source

item number

4801269

carbon footprint (A-C) embodied carbon

0.15kgCO2e

data source

TM65

item number

4801271

carbon footprint (A-C) embodied carbon

0.23kgCO2e

data source

TM65

item number

4801280

carbon footprint (A-C) embodied carbon

0.18kgCO2e

data source

TM65

item number

4801291

carbon footprint (A-C) embodied carbon

0.25kgCO2e

data source

TM65

item number

4801302

carbon footprint (A-C) embodied carbon

0.34kgCO2e

data source

TM65

item number

4801313

carbon footprint (A-C) embodied carbon

0.28kgCO2e

data source

TM65

item number

4801324

carbon footprint (A-C) embodied carbon

0.35kgCO2e

data source

TM65

item number

4801335

carbon footprint (A-C) embodied carbon

0.47kgCO2e

data source

TM65

item number

4801346

carbon footprint (A-C) embodied carbon

0.22kgCO2e

data source

TM65

item number

4801357

carbon footprint (A-C) embodied carbon

0.51kgCO2e

data source

TM65

item number

4801368

carbon footprint (A-C) embodied carbon

0.68kgCO2e

data source

TM65

item number

4801379

carbon footprint (A-C) embodied carbon

0.55kgCO2e

data source

TM65

item number

4801381

carbon footprint (A-C) embodied carbon

0.78kgCO2e

data source

TM65

item number

4805691

carbon footprint (A-C) embodied carbon

0.44kgCO2e

data source

TM65

item number

4801390

carbon footprint (A-C) embodied carbon

0.82kgCO2e

data source

TM65

item number

4806076

carbon footprint (A-C) embodied carbon

3.58kgCO2e

data source

TM65

item number

4801401

carbon footprint (A-C) embodied carbon

0.77kgCO2e

data source

TM65

item number

4801412

carbon footprint (A-C) embodied carbon

0.89kgCO2e

data source

TM65

item number

4801423

carbon footprint (A-C) embodied carbon

1.21kgCO2e

data source

TM65

item number

4801434

carbon footprint (A-C) embodied carbon

1.71kgCO2e

data source

TM65
