group: 6092G
The VSH XPress 6092G is a gunmetal 90° elbow with a press and a male thread end. By using VSH XPress in your piping installation you can install in a quick, easy and clean way. VSH XPress provides a complete piping system suitable for every conceivable application.
potable water
heating
cooling
compressed air
vacuum
residential
commercial building
industry
shipbuilding
ATG
BSI Kitemark
DNV-GL
DVGW Wasser
KIWA
ÖVGW Wasser
QB (CSTBat)
RISE
SINTEF
ÜA
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
12xR1/2"
dimensions
20x37x47 mm
weight
0.07 kg
packaging
bag (5 pce)
gtin
05022050197870
item number
size
15xR3/8"
dimensions
20x35x50 mm
weight
0.07 kg
packaging
bag (5 pce)
gtin
05022050124494
item number
size
15xR1/2"
dimensions
20x45x50 mm
weight
0.08 kg
packaging
bag (10 pce)
gtin
05022050014061
item number
size
18xR1/2"
dimensions
25x50x55 mm
weight
0.1 kg
packaging
bag (5 pce)
gtin
05022050124654
item number
size
18xR3/4"
dimensions
25x40x65 mm
weight
0.1 kg
packaging
bag (5 pce)
gtin
05022050198303
item number
size
22xR3/4"
dimensions
30x60x65 mm
weight
0.14 kg
packaging
bag (5 pce)
gtin
05022050014078
item number
size
28xR1"
dimensions
35x75x80 mm
weight
0.25 kg
packaging
bag (5 pce)
gtin
05022050014085
item number
size
35xR1 1/4"
dimensions
45x70x75 mm
weight
0.32 kg
packaging
bag (5 pce)
gtin
05022050014092
item number
size
42xR1 1/2"
dimensions
50x75x110 mm
weight
0.46 kg
packaging
bag (1 pce)
gtin
05022050383372
item number
size
54xR2"
dimensions
65x95x125 mm
weight
0.69 kg
packaging
bag (1 pce)
gtin
05022050383389
item number
size
d1
DN1
l1
z1
d2
DN2
l2
slw2
radius
angle
item number
4800939size
12xR1/2"
d1
12.0
DN1
DN10
l1
40
z1
23
d2
21.3
DN2
1/2" (DN15)
l2
18
slw2
26
radius
14
angle
90
item number
4800941size
15xR3/8"
d1
15.0
DN1
DN12
l1
43
z1
12
d2
17.2
DN2
3/8" (DN10)
l2
18
slw2
18
radius
18
angle
90
item number
4800950size
15xR1/2"
d1
15.0
DN1
DN12
l1
38
z1
19
d2
21.3
DN2
1/2" (DN15)
l2
26
slw2
18
radius
18
angle
90
item number
4800961size
18xR1/2"
d1
18.0
DN1
DN15
l1
42
z1
15
d2
21.3
DN2
1/2" (DN15)
l2
29
slw2
18
radius
22
angle
90
item number
4800972size
18xR3/4"
d1
18.0
DN1
DN15
l1
47
z1
18
d2
26.9
DN2
3/4" (DN20)
l2
22
slw2
25
radius
22
angle
90
item number
4800983size
22xR3/4"
d1
22.0
DN1
DN20
l1
47
z1
28
d2
26.9
DN2
3/4" (DN20)
l2
34
slw2
25
radius
26
angle
90
item number
4800994size
28xR1"
d1
28.0
DN1
DN25
l1
58
z1
36
d2
33.7
DN2
1" (DN25)
l2
43
slw2
33
radius
34
angle
90
item number
4801005size
35xR1 1/4"
d1
35.0
DN1
DN32
l1
55
z1
30
d2
42.4
DN2
1 1/4" (DN32)
l2
34
slw2
40
radius
42
angle
90
item number
4801016size
42xR1 1/2"
d1
42.0
DN1
DN40
l1
62
z1
32
d2
48.3
DN2
1 1/2" (DN40)
l2
38
slw2
50
radius
50
angle
90
item number
4801027size
54xR2"
d1
54.0
DN1
DN50
l1
70
z1
35
d2
60.3
DN2
2" (DN50)
l2
47
slw2
60
radius
65
angle
90
color
copper
materials
bronze (EN CC499K)
finishing
none
shape
Bend, reducer (90º)
connection type
press (M), R - male thread gas conical (BSPT)
sealing
EPDM
product group
fittings
ETIM class
EC003024 Fitting with 2 connections
HS code
74122000
brand
VSH
series
XPress Copper
type
6092G
UNSPS
40172103
SCIP
966cd6bc-74ae-47a8-951b-016935a13ff8
max operating pressure liquid
16 bar
min. medium temperature
-20 °C
max medium temperature
110 °C
peak medium temperature
135 °C
label
value
label
ETIM class
label
Material connection 1
value
Bronze
label
Material quality connection 1
value
CuSn5Zn5Pb2
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Material connection 2
value
Bronze
label
Material quality connection 2
value
CuSn5Zn5Pb2
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Bend
label
Model
value
1-part
label
Bend angle
value
90°
label
Eccentric
value
No
label
System specific
value
Yes
label
Connection 1
value
Press sleeve
label
Contour code connection 1
value
M
label
Connection 2
value
External thread conical BSPT-R (ISO 7-1 / EN 10226-1)
label
Main colour fitting
value
Copper
label
Flange compression class (PN)
value
PN 16
label
Material sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
With buffer stud
value
Yes
label
High tensile strength
value
Yes
label
Medium temperature (continuous)
value
-20°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-4°F - 230°F
label
Max. operating pressure at 20 °C
value
16bar
label
Max. operating pressure at 20 °C (imperial)
value
232.06psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With connection indicator
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
DIN-CERTCO certificate
value
No
label
VdS quality mark
value
No
label
With approval for TÜV
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
Yes
label
Certified according to NF 545
value
No
label
KIWA certified
value
Yes
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
label
Type approval according to BBR/EKS
value
No
