VSH Clamp corner T-piece (3 x clamp)

VSH Clamp corner T-piece (3 x clamp)

115

The VSH Clamp 113 is a galvanized brass corner T-piece with three clamp ends. Easy installation and high quality are the top priorities of the VSH Clamp product range.

  • simple installation with standard tools
  • quick connection technology allowing reassembly

applications

heating

solutions

building installations industry
item number size weight dimensions packaging gtin
6322877 15 0.13 kg 33x43x43 mm bag (10 pce) 08711985133219
6322901 22 0.24 kg 59x50x50 mm bag (10 pce) 08711985133233
item number size d1 DN1 l1 z1 slw1 d2 DN2 l2 z2 slw2 d3 DN3 l3 z3 slw3
6322877 15 15.0 DN12 33 11 24 15.0 DN12 31 10 24 15.0 DN12 33 11 24
6322901 22 22.0 DN20 37 13 32 22.0 DN20 37 13 32 22.0 DN20 37 13 32
see above for the diagram related to these dimensions
color silver
materials brass (CW617N)
finishing galvanised
manufacturer Aalberts integrated piping systems B.V. (VSH)
shape Angled T-piece (90Āŗ)
connection type clamp
sealing Plastic sealing
product group fittings (demountable)
ETIM class EC003025 Fitting with 3 connections
HS code 74122000
brand VSH
series Clamp
type 115
UNSPS 40174601
SCIP 98ab3390-1a8e-4560-943d-8a0d9c101b3e
label value
ETIM class EC003025 Fitting with 3 connections
Material connection 1 Brass
Material quality connection 1 CuZn40Pb2 (CW617N)
Surface protection connection 1 Galvanic/electrolytic zinc plated
Material connection 2 Brass
Material quality connection 2 CuZn40Pb2 (CW617N)
Surface protection connection 2 Galvanic/electrolytic zinc plated
Material connection 3 Brass
Material quality connection 3 CuZn40Pb2 (CW617N)
Surface protection connection 3 Galvanic/electrolytic zinc plated
Angle 90°
Swept entry type (with inner radius) No
Reducing No
Multi-part No
System specific Yes
Connection 1 Clamp connection
Connection 2 Clamp connection
Connection 3 Clamp connection
Flange compression class PN 10
Main colour fitting Grey
High tensile strength Yes
Max. operating pressure at 20 °C 6bar
Max. operating pressure at 20 °C (imperial) 87.02psi
Medium temperature (continuous) 0°C - 90°C
Medium temperature (continuous) (imperial) 32°F - 194°F
With sealing rings/gaskets No
With drain valve No
With de-aerator No
With thermal insulation No
With buffer stud No
Capped No
With connection indicator No
FM quality mark No
LPCB quality mark No
ULC quality mark No
UL quality mark No
DIN-CERTCO certificate No
VdS quality mark No
With approval for TÜV No
DVGW quality mark for gas No
DVGW quality mark for water No
KIWA certified No
Gastec QA mark No
KOMO certified No
Type approval according to BBR/EKS No
