Product Image for VSH Shurjoint swing check valve (2 x groove)

Product Image for VSH Shurjoint swing check valve (2 x groove)

group: SJ-900

VSH Shurjoint grooved pipe systems consist of a wide range of groove couplings, fittings and valves for heating, compressed air and industry. VSH Shurjoint is less labor intensive, safer, cleaner and delivers consistent connection quality.

VSH Shurjoint can be perfectly combined with other VSH systems such as VSH XPress, VSH SudoPress and VSH PowerPress
the 'Aalberts integrated piping systems' range covers a fully integrated system from ¼" to 104"

read more

read less

if the download did not start automatically, click here

PDF generation failed, please try again later

heating

cooling

compressed air

show all

show less

industry

utility

show all

show less

CRN

show all

show less

code

size

dimensions

weight

packaging

gtin

code

size

-

dimensions

190x114x159 mm

weight

4.82 kg

packaging

Bag (1 pce)

gtin

04710574649517

code

size

3"

dimensions

178x114x159 mm

weight

4.75 kg

packaging

Bag (1 pce)

gtin

04710574649524

code

size

4"

dimensions

216x146x197 mm

weight

8.34 kg

packaging

Bag (1 pce)

gtin

04710574649531

code

size

-

dimensions

330x218x292 mm

weight

23.48 kg

packaging

Bag (1 pce)

gtin

08711985446098

code

size

-

dimensions

305x210x292 mm

weight

23.5 kg

packaging

Bag (1 pce)

gtin

08711985446104

code

size

6"

dimensions

305x210x292 mm

weight

23.5 kg

packaging

Bag (1 pce)

gtin

08711985446111

code

size

8"

dimensions

365x266x357 mm

weight

45.26 kg

packaging

Bag (1 pce)

gtin

08711985446128

code

size

10"

dimensions

508x365x457 mm

weight

99 kg

packaging

Bag (1 pce)

gtin

08711985446135

code

size

12"

dimensions

610x394x544 mm

weight

155.6 kg

packaging

Bag (1 pce)

gtin

08711985446142

code

size

d1

DN1

l1

d2

DN2

l2

V

U

code

size

-

d1

76.1

DN1

2-1/2"

l1

88

d2

76.1

DN2

2-1/2"

l2

102

V

95

U

73

code

size

3"

d1

88.9

DN1

3"

l1

76

d2

88.9

DN2

3"

l2

102

V

95

U

73

code

size

4"

d1

114.3

DN1

4"

l1

89

d2

114.3

DN2

4"

l2

127

V

117

U

80

code

size

-

d1

139.7

DN1

5"

l1

136

d2

139.7

DN2

5"

l2

194

V

178

U

93

code

size

-

d1

165.1

DN1

6"

l1

127

d2

165.1

DN2

6"

l2

178

V

178

U

114

code

size

6"

d1

168.3

DN1

6"

l1

127

d2

168.3

DN2

6"

l2

178

V

178

U

114

code

size

8"

d1

219.1

DN1

8"

l1

111

d2

219.1

DN2

8"

l2

254

V

217

U

151

code

size

10"

d1

273.0

DN1

10"

l1

254

d2

273.0

DN2

10"

l2

254

V

273

U

272

code

size

12"

d1

323.9

DN1

12"

l1

305

d2

323.9

DN2

12"

l2

305

V

327

U

312

product info

item

VSH Shurjoint swing check valve (2 x groove)

item number with gtin

SJ-900

manufacturer

Shurjoint

weight

155.6 kg

dimensions

610x394x544 mm

characteristics

color

black

materials

cast iron (ASTM A536 65-45-12)

finishing

varnished

shape

straight

connection type

groove (fitting)

pressure rating (PN)

PN 20

sealing

EPDM

technical

max operating pressure liquid

20 bar

min. medium temperature

-34 cel

max medium temperature

110 cel

general

product group

afsluiters (check valves)

ETIM class

EC011469 Check valve

HS code

84813091

brand

VSH

series

Shurjoint

type

SJ-900

UNSPS

40141634

image for SJ-900

image | png

SJ-900

image for Diagram

diagram | png

Diagram

datasheet | pdf

Datasheet

installation- & maintenance document | pdf

Installation Instruction

certificate | pdf

CRN Valves

label

value

label

etim-class

value

EC011469 Check valve

label

Surface protection

value

Coated

label

Connections

value

Groove

label

Article compression class

value

PN 20

label

Sealing

value

Ethylene-propylene diene monomer rubber (EPDM)

label

Backflow safeguard according to EN 1717

value

EB

label

Angle of non-return valve

value

label

Medium temperature (continuous)

value

-34°C - 110°C

label

Medium temperature (continuous) (imperial)

value

-29.2°F - 230°F

label

Max. operating pressure at 20 °C

value

20bar

label

Max. operating pressure at 20 °C (imperial)

value

290.08psi

label

FM quality mark

value

No

label

UL quality mark

value

No

label

ULC quality mark

value

No

label

LPCB quality mark

value

No

label

Suitable for central heating water

value

Yes

label

Certified according to SVGW for water

value

No

label

Certified according to SVGW for gas

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

KIWA certified

value
