S1240
The VSH Super S1240 is a 90° wall plate with a compression and a female thread end. VSH Super provides a large assortment of fittings for every application, designed for optimum installation convenience. Easy installation and high quality are the top priorities of the VSH Super product range.
applications
solutions
approvals
| item number | size | weight | dimensions | packaging | gtin |
|---|---|---|---|---|---|
| 0865238 | 12xG1/2" | 0.14 kg | 60x49x45 mm | bag (25 pce) | 08711985019537 |
| 0897006 | 12xRp1/2" DZR Cr | 0.14 kg | 60x49x41 mm | bag (10 pce) | 08711985062397 |
| 0865007 | 15xG1/2" | 0.15 kg | 61x49x45 mm | bag (25 pce) | 08711985019551 |
| 0873061 | 15xG1/2" Ni | 0.14 kg | 61x49x45 mm | bag (25 pce) | 08711985023404 |
| 0881925 | 15xRp1/2" DZR | 0.14 kg | 61x49x41 mm | bag (10 pce) | 08711985062298 |
| 0897017 | 15xRp1/2" DZR Cr | 0.15 kg | 61x49x41 mm | bag (10 pce) | 08711985062410 |
| 0865018 | 22xG3/4" | 0.23 kg | 64x55x50 mm | bag (10 pce) | 08711985019575 |
| item number | size | d1 | DN1 | l1 | z1 | slw1 | d2 | DN2 | l2 | z2 | radius | angle |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0865238 | 12xG1/2" | 12.0 | DN10 | 35 | 16 | 19 | 21.3 | 1/2" (DN15) | 28 | 14 | 20 | 120 |
| 0897006 | 12xRp1/2" DZR Cr | 12.0 | DN10 | 35 | 16 | 19 | 21.3 | 1/2" (DN15) | 24 | 14 | 20 | 120 |
| 0865007 | 15xG1/2" | 15.0 | DN12 | 36 | 14 | 24 | 21.3 | 1/2" (DN15) | 28 | 14 | 20 | 120 |
| 0873061 | 15xG1/2" Ni | 15.0 | DN12 | 36 | 14 | 24 | 21.3 | 1/2" (DN15) | 28 | 14 | 20 | 120 |
| 0881925 | 15xRp1/2" DZR | 15.0 | DN12 | 36 | 14 | 24 | 21.3 | 1/2" (DN15) | 24 | 14 | 20 | 120 |
| 0897017 | 15xRp1/2" DZR Cr | 15.0 | DN12 | 36 | 14 | 24 | 21.3 | 1/2" (DN15) | 24 | 14 | 20 | 120 |
| 0865018 | 22xG3/4" | 22.0 | DN20 | 41 | 17 | 32 | 26.9 | 3/4" (DN20) | 29 | 12 | 23 | 120 |
| color | brass, silver, chrome |
|---|---|
| materials | brass (CW602N (DZR), CW617N) |
| finishing | chromed, nickel-plated, none |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| shape | Wall plate (120º) |
| connection type | compression |
| sealing | Brass |
| product group | fittings |
|---|---|
| ETIM class | EC003099 Wall plate |
| HS code | 74122000 |
| brand | VSH |
| series | Super |
| type | S1240 |
| SCIP | 1e5d1bf2-d72d-4b8f-ba91-73f637c5ac6d |
EPD-VSH-Super-Brass Environmental Product Declaration |
download | |
MSDS_VSH_Super link to sheet |
download | |
 S1240_Chroom image |
png | download |
VSH Super Gas GASTEC QA 10-54mm certifications |
download | |
VSH Super Gas instructions installation- & maintenance document |
download | |
VSH Super Gastec H2 certifications |
download | |
VSH Super KIWA Water 10-54 mm certifications |
download | |
VSH Super Knel water 15-42 mm ETA certifications |
download | |
VSH Super PEX ETA 10-22 mm water certifications |
download | |
VSH Super RISE certifications |
download | |
VSH_Super_Knel_instructie_NL installation- & maintenance document |
download | |
VSH_Super_water_SINTEF certifications |
download | |
 Diagram diagram |
png | download |
 S1240 image |
png | download |
| label | value |
|---|---|
| ETIM class | EC003099 Wall plate |
| Housing material | Brass |
| Shape | Right-angled |
| System specific | Yes |
| Connection | Compression ring |
| Medium temperature (continuous) | -35°C - 200°C |
| Medium temperature (continuous) (imperial) | -31°F - 392°F |
| Max. operating pressure at 20 °C | 10bar |
| Max. operating pressure at 20 °C (imperial) | 145.04psi |
| With connection indicator | No |
| With protective cap | No |
| DVGW quality mark for gas | No |
| DVGW quality mark for water | No |
| KOMO certified | No |
