VSH MultiPress to VSH SudoPress connector (2 x press)

VSH MultiPress to VSH SudoPress connector (2 x press)

K7228

The VSH MultiPress K7228 is a straight connector with a press- and VSH SudoPress end. With VSH MultiPress, Aalberts integrated piping systems provides in a reliable and high-quality plastic tube system. VSH MultiPress is the ideal plastic tube system due to its handy features.

  • Pressable with both U- and TH-profile
  • Color coding per size
  • Optimal positioning of the press jaw for fast and secure pressing
  • Leak Before Pressed function up to 32 mm

applications

potable water heating cooling compressed air

solutions

building installations

approvals

KIWA KOMO QB (CSTBat)
item number size weight dimensions packaging gtin
123459836 16x15 0.05 kg 54x23x23 mm bag (20 pce) 08711985513370
123459837 16x16 0.05 kg 54x24x24 mm bag (20 pce) 08711985513400
123459838 20x22 0.07 kg 55x31x31 mm bag (5 pce) 08711985513431
123459839 25x22 0.1 kg 62x31x31 mm bag (5 pce) 08711985513462
item number size d1 DN1 l1 z1 d2 DN2 l2 z2
123459836 16x15 16.0 DN12 28 5 15.0 DN12 26 4
123459837 16x16 16.0 DN12 28 5 16.0 DN12 26 4
123459838 20x22 20.0 DN15 28 5 22.0 DN20 27 4
123459839 25x22 25.0 DN20 35 3 22.0 DN20 27 4
see above for the diagram related to these dimensions
color bronze
materials bronze (EN CC499K)
finishing none
manufacturer Aalberts integrated piping systems B.V. (VSH)
shape straight
connection type press (U, TH/U), press (V)
sealing EPDM
product group fittings
ETIM class EC003024 Fitting with 2 connections
HS code 74122000
brand VSH
series MultiPress
type K7228
label value
ETIM class EC003024 Fitting with 2 connections
Material connection 1 Bronze
Material quality connection 1 CuSn5Zn5Pb2
Surface protection connection 1 Untreated
Surface treatment connection 1 Untreated
Material connection 2 Bronze
Material quality connection 2 CuSn5Zn5Pb2
Surface protection connection 2 Untreated
Surface treatment connection 2 Untreated
Shape Straight
Model 1-part
Reducing No
Eccentric No
System specific Yes
Connection 1 Press sleeve
Connection 2 Press sleeve
Contour code connection 2 V
Main colour fitting Bronze
Flange compression class PN 10
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With buffer stud Yes
Medium temperature (continuous) -20°C - 70°C
Medium temperature (continuous) (imperial) -4°F - 158°F
Max. operating pressure at 20 °C 10bar
Max. operating pressure at 20 °C (imperial) 145.04psi
With thermal insulation No
With sealing rings/gaskets No
Capped No
With connection indicator Yes
With drain valve No
With de-aerator No
FM quality mark No
LPCB quality mark No
ULC quality mark No
UL quality mark No
VdS quality mark No
DVGW quality mark for gas No
DVGW quality mark for water No
Certified according to NF 545 No
Gastec QA mark No

accessories

item number description
3840021 VSH MultiPress ML tube 16x2.0 coil 100m
3850341 Novopress jaw PB1 U 25
3850330 Novopress jaw PB1 U 20
3840012 VSH MultiPress ML tube 16x2.0 coil 200m
6580035 Novopress jaw PB1 V22
3850902 Novopress jaw PB1 TH 20
123459800 VSH MultiPress ML tube 16x2.0 length 5m
3850440 Novopress jaw PB2 U 25
3850319 Novopress jaw PB1 U 16
6580090 Novopress jaw PB2 V22
3850431 Novopress jaw PB2 U 20
3850901 Novopress jaw PB1 TH 16
3840045 VSH MultiPress ML tube 25x2.5 coil 50m
3852035 Novopress jaw PB2 TH 20
6580013 Novopress jaw PB1 V15
123459802 VSH MultiPress ML tube 25x2.5 length 5m
6580277 Novopress jaw PB1 V16
3850418 Novopress jaw PB2 U 16
6569838 VSH SudoPress O-ring EPDM LBP 22
3840034 VSH MultiPress ML tube 20x2.0 coil 100m
3852013 Novopress jaw PB2 TH 16
123459801 VSH MultiPress ML tube 20x2.0 length 5m
6580079 Novopress jaw PB2 V15
6580299 Novopress jaw PB2 V16
6569816 VSH SudoPress O-ring EPDM LBP 15
6673435 VSH SudoPress Copper O-ring EPDM LBP 16

contains

item number description
6569816 VSH SudoPress O-ring EPDM LBP 15 1
6673435 VSH SudoPress Copper O-ring EPDM LBP 16 1
6569838 VSH SudoPress O-ring EPDM LBP 22 1
