Novopress jaw PB1 U-profile

Novopress jaw PB1 U-profile

K5725

The Novopress PB1 U-profile is an press jaw, applicable for the ACO102/3 press machines. Novopress tools are applicable for different types of usage and material. With the wide range of Novopress tools you create quality and tight pipe connections, whether they are made of stainless steel, carbon steel, copper, plastics with PEX or multilayer pipes and fittings.

  • Suitable for the VSH Multipress productline (U-Profile)

applications

potable water natural gas heating compressed air

solutions

building installations industry
item number size weight dimensions packaging gtin
3850308 U14 1.22 kg 105x125x36 mm carton (1 pce) 08711985245349
3850319 U16 1.22 kg 105x125x36 mm carton (1 pce) 08711985464702
3850330 U20 1.22 kg 105x130x36 mm carton (1 pce) 08711985464641
3850341 U25 1.22 kg 105x145x36 mm carton (1 pce) 08711985464658
3850352 U32 1.22 kg 105x145x36 mm carton (1 pce) 08711985464665
3850363 U40 1.22 kg 120x100x30 mm carton (1 pce) 08711985365283
color black
materials steel
manufacturer Aalberts integrated piping systems B.V. (VSH)
product group tools (press tools)
ETIM class EC012046 Pressing jaw/collar for press fittings
HS code 82034000
brand VSH
series MultiPress
type K5725
label value
ETIM class EC012046 Pressing jaw/collar for press fittings
Type Pressing jaw
Contour code U
