VSH Super gas ball valve with union nut (2 x compression)

group: K1025

VSH Super gas ball valve K1025 has VSH Super compression ends with union coupling on one end. The valve as CE-marking and Gastec Qa approval. The valve is operated with a yellow knob. This valve can be connected to our other piping systems such as VSH XPress, VSH SudoPress and VSH MultiPress that have Gastec Qa approval.
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

natural gas

natural gas

segments

residential

residential

commercial building

commercial building

industry

industry

approvals

CE

CE

GASTEC

GASTEC

item number

size

d1

DN1

l1

z1

slw1

d2

DN2

l2

z2

slw2

slw0

M

Y

V

U

item number

0604736

size

15

d1

15.0

DN1

DN12

l1

36

z1

14

slw1

24

d2

15.0

DN2

DN12

l2

60

z2

38

slw2

24

slw0

17

M

36

Y

15

V

19

U

19

item number

0604505

size

22

d1

22.0

DN1

DN20

l1

40

z1

15

slw1

32

d2

22.0

DN2

DN20

l2

73

z2

49

slw2

32

slw0

24

M

36

Y

15

V

24

U

19

item number

0604747

size

22x15

d1

22.0

DN1

DN20

l1

37

z1

13

slw1

24

d2

15.0

DN2

DN20

l2

61

z2

37

slw2

24

slw0

17

M

36

Y

15

V

19

U

15

item number

size

Y

V

U

15

15

19

19

22

15

24

19

22x15

15

19

15

technical drawing for product

characteristics

color

brass

materials

brass (CW617N)

finishing

none

manufacturer

Aalberts integrated piping systems B.V. (VSH)

shape

straight, reducer

connection type

compression

sealing

Neoprene

general

product group

valves (ball valves, gas valves)

ETIM class

EC011015 Gas valve

HS code

84814090

brand

VSH

series

Super

type

K1025

UNSPS

40141607

SCIP

4164f411-1503-4f1c-9573-17d1ce0b4799

label

value

label

ETIM class

label

Housing material

value

Brass

label

Housing material quality

value

CuZn40Pb2 (CW617N)

label

Surface protection housing

value

Untreated

label

Connection 1

value

Compression ring

label

With coupling connection 1

value

No

label

Connection 2

value

Compression ring

label

With coupling connection 2

value

Yes

label

Approved according to EN 331

value

Yes

label

Operation

value

Button (expired)

label

Length of handle/diameter of hand wheel

value

36mm

label

Length of handle/diameter of hand wheel (imperial)

value

1.42"

label

DVGW quality mark for gas

value

No

label

Gastec QA mark

value

Yes
