group: I2640
heating
commercial building
CE
item number
size
dimensions
weight
packaging
gtin
item number
size
R1/2"xG1/2"
dimensions
42x32x74 mm
weight
0.16 kg
packaging
carton (1 pce)
gtin
08711985164848
color
brass, red
materials
brass
shape
Perpendicular
connection type
R - male thread gas conical (BSPT), G - female thread gas cylindrical (BSPP)
sealing
EPDM, PTFE
product group
safety valves (safety valves)
ETIM class
EC011311 Safety valve
HS code
74031900
brand
VSH
type
I2640
SCIP
960cbc9d-b80b-4294-a3a9-1f32dc84ed9f
max operating pressure liquid
3 bar
label
value
label
ETIM class
value
label
Connection 1
value
External thread conical BSPT-R (ISO 7-1 / EN 10226-1)
label
Nominal diameter connection 1
value
1/2 inch (15)
label
Outer pipe diameter connection 1
value
21.3mm
label
Outer pipe diameter connection 1 (imperial)
value
0.84"
label
Connection 2
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
Nominal diameter connection 2
value
1/2 inch (15)
label
Max. operating pressure at 20 °C
value
3bar
label
Max. operating pressure at 20 °C (imperial)
value
43.51psi
label
Length of connection 1
value
29mm
label
Length of connection 1 (imperial)
value
1.14"
label
Length of connection 2
value
26mm
label
Length of connection 2 (imperial)
value
1.02"
label
Working length connection 2
value
17.5mm
label
Working length connection 2 (imperial)
value
0.69"
label
Height
value
74mm
label
Height (imperial)
value
2.91"
label
Suitable for heating
value
Yes
label
Suitable for cooling
value
No
label
Suitable for solar heating
value
No
label
Suitable for hot tap water
value
No
