VSH Super Gas Belgium angle adapter 90° (compression x female thread)

group: G1214

The VSH Super G1214 is a 90° angle adapter with a compression and a female thread end. This is a special Gas fitting, designed for Belgium only. VSH Super provides a large assortment of fittings for every application, designed for optimum installation convenience. Easy installation and high quality are the top priorities of the VSH Super product range.

  • special Gas fitting for the Belgium market
  • simple installation with standard tools
  • quick connection technology allowing reassembly
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

natural gas

natural gas

hydrogen (H2)

hydrogen (H2)

segments

residential

residential

commercial building

commercial building

industry

industry

approvals

ARGB-KVBG

ARGB-KVBG

GASTEC

GASTEC

Gastec-H2-ready

Gastec-H2-ready

item number

size

d1

DN1

l1

z1

slw1

d2

DN2

l2

z2

slw0

item number

0879142

size

12xRp1/2"

d1

12.0

DN1

DN10

l1

43

z1

16

slw1

21

d2

21.3

DN2

1/2" (DN15)

l2

28

z2

13

slw0

14

item number

0879560

size

15xRp1/2"

d1

15.0

DN1

DN12

l1

46

z1

15

slw1

24

d2

21.3

DN2

1/2" (DN15)

l2

23

z2

14

slw0

17

item number

0876656

size

18xRp1/2"

d1

18.0

DN1

DN15

l1

50

z1

15

slw1

27

d2

21.3

DN2

1/2" (DN15)

l2

29

z2

14

slw0

22

item number

0879571

size

22xRp3/4"

d1

22.0

DN1

DN20

l1

56

z1

18

slw1

32

d2

26.9

DN2

3/4" (DN20)

l2

33

z2

16

slw0

24

item number

0879582

size

22xRp1"

d1

22.0

DN1

DN20

l1

59

z1

21

slw1

32

d2

33.7

DN2

1" (DN25)

l2

38

z2

19

slw0

24

item number

0879043

size

28xRp1"

d1

28.0

DN1

DN25

l1

63

z1

21

slw1

39

d2

33.7

DN2

1" (DN25)

l2

34

z2

15

slw0

30

technical drawing for product

characteristics

color

brass

materials

brass (CW617N)

finishing

none

manufacturer

Aalberts integrated piping systems B.V. (VSH)

shape

Elbow, reducer (90º)

connection type

compression, Rp - female thread cylindrical (BSPT)

sealing

Brass

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

74122000

brand

VSH

series

Super Gas Belgium

type

G1214

SCIP

1e5d1bf2-d72d-4b8f-ba91-73f637c5ac6d

label

value

label

Material connection 1

value

Brass

label

Material quality connection 1

value

CuZn40Pb2 (CW617N)

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Brass

label

Material quality connection 2

value

CuZn40Pb2 (CW617N)

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Bend

label

Model

value

1-part

label

Bend angle

value

90°

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Compression ring

label

Connection 2

value

Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)

label

Main colour fitting

value

Brass

label

Material sealing

value

Brass

label

With buffer stud

value

Yes

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-20°C - 60°C

label

Medium temperature (continuous) (imperial)

value

-4°F - 140°F

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

KOMO certified

value

No
