VSH Threaded hose connection (male thread x hose connector)

group: D1114

The VSH Threaded D1114 is a hose connection with a male thread and hose connection end. VSH Threaded provides a wide assortment of fittings for every application. Ease of use and high quality are our top priorities in the VSH Threaded range.

  • manufactured from first class brass
  • same fitting applications for water and gas
  • provided with all relevant approvals
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

potable water

potable water

heating

heating

compressed air

compressed air

segments

commercial building

commercial building

industry

industry

approvals

no approvals available

item number

size

dimensions

weight

packaging

gtin

item number

0454003

size

R1/4"xØ1/4

dimensions

34x17x17 mm

weight

0.02 kg

packaging

bag (10 pce)

gtin

08711985005219

item number

0454036

size

R3/8"xØ3/8

dimensions

35x20x20 mm

weight

0.02 kg

packaging

bag (10 pce)

gtin

08711985005257

item number

0454047

size

R1/2"xØ1/2

dimensions

48x28x28 mm

weight

0.05 kg

packaging

bag (10 pce)

gtin

08711985005271

item number

0454058

size

R3/4"xØ3/4

dimensions

48x35x35 mm

weight

0.07 kg

packaging

bag (5 pce)

gtin

08711985006131

item number

size

d1

DN1

l1

slw1

d2

DN2

l2

item number

0454003

size

R1/4"xØ1/4

d1

13.5

DN1

1/4" (DN8)

l1

10

slw1

14

d2

9.0

DN2

1/4" (DN8)

l2

24

item number

0454036

size

R3/8"xØ3/8

d1

17.2

DN1

3/8" (DN10)

l1

11

slw1

17

d2

12.0

DN2

3/8" (DN10)

l2

24

item number

0454047

size

R1/2"xØ1/2

d1

21.3

DN1

1/2" (DN15)

l1

14

slw1

24

d2

15.0

DN2

1/2" (DN15)

l2

34

item number

0454058

size

R3/4"xØ3/4

d1

26.7

DN1

3/4" (DN20)

l1

15

slw1

30

d2

21.0

DN2

3/4" (DN20)

l2

34

technical drawing for product

characteristics

color

brass

materials

brass (CW614N, CW617N)

finishing

none

shape

straight

connection type

R - male thread gas conical (BSPT), hose connector

general

product group

fittings (demountable)

ETIM class

EC011233 Hose connector/threaded coupling

HS code

74122000

brand

VSH

series

Threaded

type

D1114

UNSPS

40172501

SCIP

559600c8-54a3-4cba-add8-25baf7b1777f

image for D1114

image | png

D1114

image for Diagram

diagram | png

Diagram

label

value

label

Material

value

Brass

label

Material quality

value

Other

label

Thread connection

value

External thread conical BSPT-R (ISO 7-1 / EN 10226-1)

item number

carbon footprint (A-C) embodied carbon

data source

item number

0454003

carbon footprint (A-C) embodied carbon

0.07kgCO2e

data source

TM65

item number

0454036

carbon footprint (A-C) embodied carbon

0.1kgCO2e

data source

TM65

item number

0454047

carbon footprint (A-C) embodied carbon

0.23kgCO2e

data source

TM65

item number

0454058

carbon footprint (A-C) embodied carbon

0.31kgCO2e

data source

TM65
