C9439
VSH PowerPress® C9439 is a reducer designed for thick wall steel pipe. By using VSH PowerPress® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes ½" up to and including 2".
applications
solutions
approvals
| item number | size | weight | dimensions | packaging | gtin |
|---|---|---|---|---|---|
| PWR9401073 | 3/4"x1/2" | 0.31 kg | 63x38x38 mm | bag (10 pce) | 08711985470918 |
| PWR9401084 | 1"x1/2" | 0.18 kg | 70x46x46 mm | bag (5 pce) | 08711985470925 |
| PWR9401755 | 1"x3/4" | 0.03 kg | 71x46x46 mm | bag (5 pce) | 08711985481693 |
| PWR9401766 | 1 1/4"x3/4" | 0.16 kg | 86x56x56 mm | bag (1 pce) | 08711985481723 |
| PWR9401777 | 1 1/4"x1" | 0.27 kg | 89x56x56 mm | bag (1 pce) | 08711985481754 |
| PWR9401788 | 1 1/2"x1 1/4" | 0.36 kg | 103x62x62 mm | bag (1 pce) | 08711985481785 |
| PWR9401799 | 2"x1 1/4" | 0.45 kg | 111x74x74 mm | bag (1 pce) | 08711985481815 |
| PWR9401801 | 2"x1 1/2" | 0.58 kg | 111x74x74 mm | bag (1 pce) | 08711985481846 |
| item number | size | d1 | DN1 | l1 | z1 | d2 | DN2 | l2 | z2 |
|---|---|---|---|---|---|---|---|---|---|
| PWR9401073 | 3/4"x1/2" | 26.9 | DN20 | 34 | 3 | 21.3 | DN15 | 29 | 1 |
| PWR9401084 | 1"x1/2" | 33.7 | DN25 | 41 | 5 | 21.3 | DN15 | 29 | 1 |
| PWR9401755 | 1"x3/4" | 33.7 | DN25 | 39 | 3 | 26.9 | DN20 | 31 | 0 |
| PWR9401766 | 1 1/4"x3/4" | 42.4 | DN32 | 55 | 7 | 26.9 | DN20 | 31 | 0 |
| PWR9401777 | 1 1/4"x1" | 42.4 | DN32 | 53 | 5 | 33.7 | DN25 | 36 | 0 |
| PWR9401788 | 1 1/2"x1 1/4" | 48.3 | DN40 | 53 | 4 | 42.4 | DN32 | 50 | 2 |
| PWR9401799 | 2"x1 1/4" | 60.3 | DN50 | 61 | 8 | 42.4 | DN32 | 50 | 2 |
| PWR9401801 | 2"x1 1/2" | 60.3 | DN50 | 59 | 6 | 48.3 | DN40 | 51 | 2 |
| color | grey |
|---|---|
| materials | steel (St 35 (1.0308)) |
| finishing | zinc-nickel plated |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| shape | straight, reducer |
| connection type | press (DW) |
| sealing | EPDM |
| product group | fittings |
|---|---|
| ETIM class | EC003024 Fitting with 2 connections |
| HS code | 73079980 |
| brand | VSH |
| series | PowerPress |
| type | C9439 |
| UNSPS | 40173602 |
| SCIP | 2dc8f2fc-98c9-4447-b557-184ada83b520 |
210628_MSDS_VSH_PowerPress_EN link to sheet |
download | |
 C9439 image |
png | download |
VSH PowerPress CSTB certifications |
download | |
VSH PowerPress FM certifications |
download | |
 Diagram diagram |
png | download |
VSH PowerPress instructions installation- & maintenance document |
download | |
VSH PowerPress 3D CAD Step CAD |
zip | download |
VSH PowerPress 3D CAD IGES CAD |
zip | download |
VSH PowerPress 2D CAD dxf CAD |
zip | download |
| label | value |
|---|---|
| ETIM class | EC003024 Fitting with 2 connections |
| Material connection 1 | Steel |
| Material quality connection 1 | St 35 (1.0308) |
| Surface protection connection 1 | Zinc/nickel |
| Material connection 2 | Steel |
| Material quality connection 2 | St 35 (1.0308) |
| Surface protection connection 2 | Zinc/nickel |
| Shape | Straight |
| Model | 1-part |
| Reducing | Yes |
| Eccentric | No |
| System specific | Yes |
| Connection 1 | Press sleeve |
| Contour code connection 1 | DW |
| Connection 2 | Press sleeve |
| Contour code connection 2 | DW |
| Main colour fitting | Grey |
| Flange compression class | PN 16 |
| Material sealing | Ethylene-propylene diene monomer rubber (EPDM) |
| With buffer stud | Yes |
| High tensile strength | Yes |
| Medium temperature (continuous) | -40°C - 135°C |
| Medium temperature (continuous) (imperial) | -40°F - 275°F |
| Max. operating pressure at 20 °C | 16bar |
| Max. operating pressure at 20 °C (imperial) | 232.06psi |
| With thermal insulation | No |
| With sealing rings/gaskets | No |
| Capped | Yes |
| With connection indicator | Yes |
| With drain valve | No |
| With de-aerator | No |
| FM quality mark | Yes |
| LPCB quality mark | No |
| ULC quality mark | No |
| UL quality mark | No |
| VdS quality mark | No |
| DVGW quality mark for gas | No |
| DVGW quality mark for water | No |
| Certified according to NF 545 | No |
| KIWA certified | No |
| Gastec QA mark | No |
| KOMO certified | No |
| item number | description | |
|---|---|---|
 |
PWR9401744 | VSH PowerPress insertion depth marker 1/2"-2" |
