C1436
The VSH XPress C1436 is a carbon steel crossing pair double with 4 press and 4 tube ends. By using VSH XPress in your piping installation you can install in a quick, easy and clean way. VSH XPress provides a complete piping system suitable for every conceivable application.
applications
solutions
approvals
| item number | size | weight | dimensions | packaging | gtin |
|---|---|---|---|---|---|
| 6206750 | 12xØ12 | 0.22 kg | 260x100x31 mm | carton (8 pce) | 08711985150513 |
| 6206761 | 15xØ12 | 0.27 kg | 260x120x34 mm | carton (8 pce) | 08711985204469 |
| 6206772 | 15xØ15 | 0.32 kg | 260x120x36 mm | carton (8 pce) | 08711985204476 |
| 6206783 | 18xØ12 | 0.3 kg | 260x120x37 mm | carton (8 pce) | 08711985204483 |
| 6206794 | 18xØ15 | 0.33 kg | 260x120x40 mm | carton (8 pce) | 08711985204957 |
| 6206948 | 22xØ12 | 0.34 kg | 260x120x44 mm | carton (6 pce) | 08711985204490 |
| 6206805 | 22xØ15 | 0.37 kg | 260x120x44 mm | carton (6 pce) | 08711985204506 |
| 6206816 | 28xØ12 | 0.4 kg | 260x120x48 mm | carton (6 pce) | 08711985204513 |
| 6206827 | 28xØ15 | 0.51 kg | 260x120x50 mm | carton (6 pce) | 08711985204520 |
| 6206838 | 35xØ15 | 0.54 kg | 260x120x58 mm | carton (3 pce) | 08711985207989 |
| item number | size | d1 | DN1 | l1 | z1 | d2 | DN2 | l2 | z2 | d3 | DN3 | d4 | DN4 | d5 | DN5 | l5 | z5 | d6 | DN6 | l6 | z6 | d7 | DN7 | d8 | DN8 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6206750 | 12xØ12 | 12.0 | DN10 | 50 | 33 | 12.0 | DN10 | 50 | 33 | 12.0 | DN10 | 12.0 | DN10 | 12.0 | DN10 | 50 | 33 | 12.0 | DN10 | 50 | 33 | 12.0 | DN10 | 12.0 | DN10 |
| 6206761 | 15xØ12 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 60 | 40 | 12.0 | DN10 | 12.0 | DN10 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 60 | 40 | 12.0 | DN10 | 12.0 | DN10 |
| 6206772 | 15xØ15 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 15.0 | DN12 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 60 | 40 | 15.0 | DN12 | 15.0 | DN12 |
| 6206783 | 18xØ12 | 18.0 | DN15 | 60 | 40 | 18.0 | DN15 | 60 | 40 | 12.0 | DN10 | 12.0 | DN10 | 18.0 | DN15 | 60 | 40 | 18.0 | DN15 | 60 | 40 | 12.0 | DN10 | 12.0 | DN10 |
| 6206794 | 18xØ15 | 18.0 | DN15 | 60 | 40 | 18.0 | DN15 | 60 | 40 | 15.0 | DN12 | 15.0 | DN12 | 18.0 | DN15 | 60 | 40 | 18.0 | DN15 | 60 | 40 | 15.0 | DN12 | 15.0 | DN12 |
| 6206948 | 22xØ12 | 22.0 | DN20 | 60 | 39 | 22.0 | DN20 | 60 | 39 | 12.0 | DN10 | 12.0 | DN10 | 22.0 | DN20 | 60 | 39 | 22.0 | DN20 | 60 | 39 | 12.0 | DN10 | 12.0 | DN10 |
| 6206805 | 22xØ15 | 22.0 | DN20 | 60 | 39 | 22.0 | DN20 | 60 | 39 | 15.0 | DN12 | 15.0 | DN12 | 22.0 | DN20 | 60 | 39 | 22.0 | DN20 | 60 | 39 | 15.0 | DN12 | 15.0 | DN12 |
| 6206816 | 28xØ12 | 28.0 | DN25 | 60 | 37 | 28.0 | DN25 | 60 | 37 | 12.0 | DN10 | 12.0 | DN10 | 28.0 | DN25 | 60 | 37 | 28.0 | DN25 | 60 | 37 | 12.0 | DN10 | 12.0 | DN10 |
| 6206827 | 28xØ15 | 28.0 | DN25 | 60 | 37 | 28.0 | DN25 | 60 | 37 | 15.0 | DN12 | 15.0 | DN12 | 28.0 | DN25 | 60 | 37 | 28.0 | DN25 | 60 | 37 | 15.0 | DN12 | 15.0 | DN12 |
| 6206838 | 35xØ15 | 35.0 | DN32 | 60 | 34 | 35.0 | DN32 | 60 | 34 | 15.0 | DN12 | 15.0 | DN12 | 35.0 | DN32 | 60 | 34 | 35.0 | DN32 | 60 | 34 | 15.0 | DN12 | 15.0 | DN12 |
| color | silver |
|---|---|
| materials | steel (St 34.2 (1.0034)) |
| finishing | galvanized (electrolytically zincplated) |
| manufacturer | Aalberts integrated piping systems B.V. (VSH) |
| shape | Cross, reducer |
| connection type | press (M), Tube end, tube end, Press (M) |
| sealing | EPDM |
| product group | fittings |
|---|---|
| ETIM class | EC011717 Pass piece |
| HS code | 73079980 |
| brand | VSH |
| series | XPress Carbon |
| type | C1436 |
ATG3056_XPress_Carbon_F certifications |
download | |
 C1436 image |
png | download |
EPD-VSH-XPress-Carbon Environmental Product Declaration |
download | |
VSH XPress Carbon Lloyds Register certifications |
download | |
VSH XPress QB certifications |
download | |
VSH_XPress_Carbon-SPF certifications |
download | |
VSH_XPress_Galvanized_RINA certifications |
download | |
VSH_XPress_carbon_RISE certifications |
download | |
ATG3056_XPress_Carbon certifications |
download | |
 Diagram diagram |
png | download |
VSH XPress Carbon&Stainless Bureau Veritas certifications |
download | |
VSH XPress installation instructions installation- & maintenance document |
download |
| label | value |
|---|---|
| ETIM class | EC011717 Pass piece |
| Material | Steel |
| Material quality | St 34.2 (1.0034) |
| Surface protection | Galvanic/electrolytic zinc plated |
| Suitable for single pipe system | No |
| Suitable for two pipe system | No |
| System specific | Yes |
| Connection 1 | Press sleeve |
| Wall thickness, connection 1 | 1.5mm |
| Connection 2 | Press sleeve |
| Wall thickness, connection 2 | 1.5mm |
| With insulating box | No |
| Contour code | M |
| KIWA certified | No |
| Gastec QA mark | No |
| KOMO certified | No |
| item number | description | |
|---|---|---|
 |
6212646 | VSH XPress C+S insert depth marker 12-108 |
 |
6211898 | Deburrer for carbon and stainless steel tube 12-54 |
 |
6206266 | VSH SudoXPress Carbon galvanized tube 12x1.2 (l=3m) |
|
6209929 | VSH SudoXPress Carbon galvanized tube 12x1.2 (l=6m) small bundle |
|
6205144 | VSH SudoXPress Carbon galvanized tube 12x1.2 (l=6m) |
 |
6222205 | VSH XPress Carbon+Stainless O-ring EPDM LBP 12 |
 |
6340708 | VSH SudoXPress Carbon galvanized tube+PP 15x1.2 small bundle |
|
6204682 | VSH SudoXPress Carbon galvanized tube+PP coating 15x1.2 |
|
6209931 | VSH SudoXPress Carbon galvanized tube 15x1.2 (l=6m) small bundle |
|
6206277 | VSH SudoXPress Carbon galvanized tube 15x1.2 (l=3m) |
|
6205155 | VSH SudoXPress Carbon galvanized tube 15x1.2 (l=6m) |
|
6222216 | VSH XPress Carbon+Stainless O-ring EPDM LBP 15 |
 |
6119401 | VSH XPress Carbon+Stainless O-ring FPM LBP 15 |
| item number | description | ||
|---|---|---|---|
|
6222205 | VSH XPress Carbon+Stainless O-ring EPDM LBP 12 | 4 |
|
6222216 | VSH XPress Carbon+Stainless O-ring EPDM LBP 15 | 4 |
