VSH End Feed brass wallplate short (solder x female thread)

group: C1040

The VSH End Feed Brass C1040 is a short wallplate with a solder and a female thread end. VSH End Feed Brass provides an assortment of fittings for every soft-solder application. High quality and great dimensional accuracy are the top priorities of the VSH End Feed Brass product range.

  • manufactured from first class brass
  • same fitting applications for water and gas
  • provided with all relevant approvals
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

potable water

potable water

heating

heating

compressed air

compressed air

segments

commercial building

commercial building

industry

industry

approvals

KIWA

KIWA

item number

size

dimensions

weight

packaging

gtin

item number

0424314

size

12xG3/8"

dimensions

40x44x27 mm

weight

0.07 kg

packaging

bag (10 pce)

gtin

08711985002195

item number

0424336

size

12xG1/2"

dimensions

44x49x27 mm

weight

0.08 kg

packaging

bag (10 pce)

gtin

08711985002232

item number

0424325

size

15xG3/8"

dimensions

42x44x28 mm

weight

0.07 kg

packaging

bag (10 pce)

gtin

08711985002218

item number

0424347

size

15xG1/2"

dimensions

46x49x33 mm

weight

0.09 kg

packaging

bag (10 pce)

gtin

08711985002256

item number

0424358

size

22xG3/4"

dimensions

58x55x38 mm

weight

0.15 kg

packaging

bag (5 pce)

gtin

08711985002270

item number

0424369

size

28xG1"

dimensions

67x63x48 mm

weight

0.26 kg

packaging

bag (2 pce)

gtin

08711985002294

item number

size

d1

DN1

l1

z1

d2

DN2

l2

z2

radius

angle

item number

0424314

size

12xG3/8"

d1

12.0

DN1

DN10

l1

18

z1

9

d2

17.2

DN2

3/8" (DN10)

l2

18

z2

8

radius

17

angle

90

item number

0424336

size

12xG1/2"

d1

12.0

DN1

DN10

l1

20

z1

11

d2

21.3

DN2

1/2" (DN15)

l2

18

z2

6

radius

20

angle

90

item number

0424325

size

15xG3/8"

d1

15.0

DN1

DN12

l1

20

z1

8

d2

17.2

DN2

3/8" (DN10)

l2

18

z2

8

radius

17

angle

90

item number

0424347

size

15xG1/2"

d1

15.0

DN1

DN12

l1

22

z1

11

d2

13.5

DN2

1/2" (DN15)

l2

21

z2

9

radius

25

angle

90

item number

0424358

size

22xG3/4"

d1

22.0

DN1

DN20

l1

30

z1

14

d2

26.9

DN2

3/4" (DN20)

l2

23

z2

11

radius

23

angle

90

item number

0424369

size

28xG1"

d1

28.0

DN1

DN25

l1

35

z1

16

d2

33.7

DN2

1" (DN25)

l2

30

z2

14

radius

26

angle

90

technical drawing for product

characteristics

color

brass

materials

brass (CW617N)

finishing

none

shape

Wall plate (90º)

connection type

solder, G - female thread gas cylindrical (BSPP)

sealing

Metal sealing

general

product group

fittings

ETIM class

EC003099 Wall plate

HS code

74122000

brand

VSH

series

End Feed

type

C1040

SCIP

9096d92f-2905-489e-9245-022c48ad808b

technical

max operating pressure liquid

25 bar

min. medium temperature

-20 °C

max medium temperature

110 °C

image for C1040

image | png

C1040

image for Diagram

diagram | png

Diagram

installation- & maintenance document | pdf

Installation instructions End Feed Brass

certifications | pdf

Reach declaration

certifications | pdf

TM65 Embodied Carbon Declaration

link to sheet | pdf

VSH End Feed MSDS

certifications | pdf

VSH Soldeer KIWA
