Broen Ballofix radiator tail piece (male thread x female thread)

Broen Ballofix radiator tail piece (male thread x female thread)

group: B3824

The B3824 Broen Ballofix radiator tail pieces are high quality, compact ball valves with high quality finishing. The design and materials used, guarantee smooth operation, even after several years of use. Due to the wide range, an optimal version is available for every application.

  • Broen Ballofix radiator tail pieces can be operated using a screwdriver or Ballofix handle
  • we recommend opening and closing Broen Ballofix ball valves twice a year & nbsp; to ensure optimal operation

applications

heating

heating

cooling

cooling

show all
show less

solutions

building installations

building installations

show all
show less

approvals

no approvals available

item number size weight dimensions packaging gtin
6004306 R3/8"xG3/8" (DN10R) 0.11 kg 60x29x29 mm carton (10 pce) 05708537784220
6001457 R1/2"xG1/2" (DN15R) Ni 0.2 kg 70x34x30 mm carton (10 pce) 05708537784695
6001479 R3/4"xG3/4" (DN15R) 0.39 kg 81x44x44 mm carton (5 pce) 05708537784619
item number size DN1 l1 DN2 l2 z2 slw0 slw1 D1
6004306 R3/8"xG3/8" (DN10R) 3/8" (DN10) 21 3/8" (DN10) 21 12 21
6001457 R1/2"xG1/2" (DN15R) Ni 1/2" (DN15) 46 1/2" (DN15) 24 14 27 30 21
6001479 R3/4"xG3/4" (DN15R) 3/4" (DN20) 52 3/4" (DN20) 29 17 35 38 27
drawing for product
color brass, chrome
materials brass (CW614N)
finishing chromed, none
manufacturer BROEN
shape straight (0º)
connection type R - male thread gas conical (BSPT), G - female thread gas cylindrical (BSPP)
pressure rating (PN) PN 10
sealing EPDM
product group valves (ball valves)
ETIM class EC010866 Radiator foot valve
HS code 84818039
brand Broen
series Ballofix
type B3824
UNSPS 40141607
SCIP e78c0723-c6e6-479c-bcc1-e395a5461292
label value
ETIM class EC010866 Radiator foot valve
Operation Screw slot
With drain possibility (connection) No
With drain valve No
