group: B3812
potable water
heating
cooling
compressed air
commercial building
industry
ETA
GDV
SINTEF
SITAC
STF
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
12 (DN10R) Cr
dimensions
43x42x23 mm
weight
0.1 kg
packaging
carton (10 pce)
gtin
05708537785425
item number
size
15 (DN10R) Cr
dimensions
51x45x27 mm
weight
0.13 kg
packaging
carton (10 pce)
gtin
05708537785524
item number
size
d1
DN1
l1
z1
slw1
d2
DN2
l2
z2
slw2
slw0
a
angle
item number
6000852size
12 (DN10R) Cr
d1
12.0
DN1
DN10
l1
31
z1
14
slw1
20
d2
12.0
DN2
DN10
l2
28
z2
11
slw2
20
slw0
21
a
90
angle
90
item number
6000874size
15 (DN10R) Cr
d1
15.0
DN1
DN12
l1
34
z1
15
slw1
24
d2
15.0
DN2
DN12
l2
30
z2
11
slw2
24
slw0
21
a
90
angle
90
color
chrome
materials
brass (CW625N (DZR))
finishing
chromed
shape
Perpendicular (90º)
connection type
compression
pressure rating (PN)
PN 10
sealing
EPDM
Bore (Full bore)
8.5 mm (No)
product group
valves (ball valves)
ETIM class
EC011343 Ball valve
HS code
84818081
brand
Broen
series
Ballofix
type
B3812
UNSPS
40141607
SCIP
e78c0723-c6e6-479c-bcc1-e395a5461292
max operating pressure liquid
10 bar
min. medium temperature
-20 °C
max medium temperature
120 °C
peak medium temperature
120 °C
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Material quality
value
Brass CW625N (CuZn35Pb1.5AlAs)
label
Surface protection housing
value
Chromium-plated
label
Material ball seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Material ball
value
Brass
label
Surface protection ball
value
Chromium-plated
label
Material spindle
value
Brass
label
Material primary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Material secondary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Connection 1
value
Compression ring
label
With coupling connection 1
value
No
label
Connection 2
value
Compression ring
label
With coupling connection 2
value
No
label
Sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Article compression class
value
PN 10
label
Flange compression class
value
PN 10
label
With drain valve
value
No
label
With drain possibility (connection)
value
No
label
With non-return valve
value
No
label
With filter
value
No
label
With thermometer
value
No
label
Model
value
Right-angled
label
With insulation shell
value
No
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Fire-safe
value
No
label
Max. pressure difference at 20 °C
value
10bar
label
Medium temperature (continuous)
value
-20°C - 120°C
label
Medium temperature (continuous) (imperial)
value
-4°F - 248°F
label
Medically clean
value
No
label
Grease-free
value
No
label
Operation
value
Screw slot
label
Housing construction
value
1-part
label
Full bore
value
No
label
Working length connection 2
value
10.5mm
label
Working length connection 2 (imperial)
value
0.41"
label
Angle of the valve
value
90°
label
Wrench width
value
21mm
label
Wrench width (imperial)
value
0.83"
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
No
item number
carbon footprint (A1-A3) cradle-to-gate
carbon footprint (A-C) embodied carbon
carbon footprint (A-D) cradle-to-cradle
data source
item number
6000852carbon footprint (A1-A3) cradle-to-gate
0.54kgCO2e
carbon footprint (A-C) embodied carbon
0.57kgCO2e
carbon footprint (A-D) cradle-to-cradle
0.56kgCO2e
data source
EPD
item number
6000874carbon footprint (A1-A3) cradle-to-gate
0.67kgCO2e
carbon footprint (A-C) embodied carbon
0.71kgCO2e
carbon footprint (A-D) cradle-to-cradle
0.7kgCO2e
data source
EPD
