group: B3805
potable water
heating
cooling
compressed air
industry
commercial building
SITAC
GDV
STF
SINTEF
WRAS
ETA
KIWA
code
size
dimensions
weight
packaging
gtin
code
size
G1/2" (DN10R) Cr
dimensions
46x31x27 mm
weight
0.11 kg
packaging
carton (10 pce)
gtin
05708537785227
code
size
DN1
l1
z1
slw1
DN2
l2
slw0
a
code
size
G1/2" (DN10R) Cr
DN1
1/2" (DN15)
l1
26
z1
26
slw1
27
DN2
1/2" (DN15)
l2
20
slw0
21
a
90
item
Broen Ballofix mini ball valve no handle (union nut x male thread)
item number with gtin
B3805 (05708537785227)
manufacturer
BROEN
size
G1/2" (DN10R) Cr
weight
0.11 kg
dimensions
46x31x27 mm
color
chrome
materials
brass (CW625N (DZR))
finishing
chromed
shape
straight
connection type
coupling nut, G - male thread gas cylindrical (BSPP)
pressure rating (PN)
PN 10
sealing
EPDM
Bore
8.5 mm (No)
max operating pressure liquid
10 bar
min. medium temperature
-20 °C
max medium temperature
120 °C
peak medium temperature
120 °C
product group
valves (ball valves)
ETIM class
EC011343 Ball valveHS code
84818081
brand
Broen
series
Ballofix
type
B3805
UNSPS
40141607
SCIP
e78c0723-c6e6-479c-bcc1-e395a5461292
label
value
label
etim-class
value
EC011343 Ball valvelabel
Housing material
value
Brass
label
Material quality
value
Brass CW625N (CuZn35Pb1.5AlAs)
label
Surface protection housing
value
Chromium-plated
label
Material ball seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Material ball
value
Brass
label
Surface protection ball
value
Chromium-plated
label
Material spindle
value
Brass
label
Material primary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Material secondary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Nominal diameter connection 1
value
1/2 inch (15)
label
With coupling connection 1
value
Yes
label
Nominal diameter connection 2
value
1/2 inch (15)
label
Connection 2
value
External thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 2
value
No
label
Sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Article compression class
value
PN 10
label
Flange compression class
value
PN 10
label
With drain valve
value
No
label
With drain possibility (connection)
value
No
label
With non-return valve
value
No
label
With filter
value
No
label
With thermometer
value
No
label
Model
value
Straight
label
With insulation shell
value
No
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Fire-safe
value
No
label
Medium temperature (continuous)
value
-20°C - 120°C
label
Medium temperature (continuous) (imperial)
value
-4°F - 248°F
label
Medically clean
value
No
label
Grease-free
value
No
label
Operation
value
Screw slot
label
Housing construction
value
2-part
label
Full bore
value
No
label
Length of connection 1
value
26.4mm
label
Length of connection 1 (imperial)
value
1.04"
label
Working length connection 1
value
26.4mm
label
Working length connection 1 (imperial)
value
1.04"
label
Length of connection 2
value
19.5mm
label
Length of connection 2 (imperial)
value
0.77"
label
Angle of the valve
value
label
Wrench width
value
21mm
label
Wrench width (imperial)
value
0.83"
label
Compliant with EU Drinking Water Directive (DWD)
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
Yes
code
carbon footprint (A1-A3) cradle-to-gate
carbon footprint (A-C) embodied carbon
carbon footprint (A-D) cradle-to-cradle
data source
code
carbon footprint (A1-A3) cradle-to-gate
0.6kgCO2e
carbon footprint (A-C) embodied carbon
0.64kgCO2e
carbon footprint (A-D) cradle-to-cradle
0.63kgCO2e
data source
EPD
