VSH Shurjoint mechanical tee (1 x female thread), EPDM gasket

Product Image for VSH Shurjoint mechanical tee (1 x female thread), EPDM gasket
Product Image for VSH Shurjoint mechanical tee (1 x female thread), EPDM gasket

group: 7721E

7721E is the designation for model 7721 with a Grade E EPDM gasket. The VSH Shurjoint Model 7721 Mechanical Tee when mounted on hole cut pipe provides a fast and easy mid-pipe threaded branch outlet. By utilizing the Model 7721 you eliminate the need for welding or the use of multiple fittings. The Mechanical Tee is com­prised of upper and lower ductile iron housing segments, a grade “E” EPDM rubber molded gasket and plated track bolts and nuts. Mechanical tees are supplied with our standard painted finishes, i.e. orange or red. Optional finishes such as hot dipped zinc galvanized and custom epoxy coatings are also available.
