VSH Shurjoint reducing tee (groove x female thread x groove)

VSH Shurjoint reducing tee (groove x female thread x groove)

7121F

Shurjoint grooved-end reducing tees are made of ductile iron per ASTM A536 Gr. 65-45-12. C-E dimensions are manufacturer’s standard.

Shurjoint standard fitting pressure ratings conform to the ratings of Model 7707 couplings.

applications

heating cooling compressed air

solutions

building installations industry
item number size weight dimensions packaging gtin
1121F2910014 76.1 xRc1 galvanized 1.95 kg 190x77x134 mm carton (10 pce) 08711985477481
1121F2920014 76.1 xRc2 galvanized 2.05 kg 190x77x134 mm carton (10 pce) 08711985477498
1121F3010014 88.9 xRc1 galvanized 2.27 kg 216x89x153 mm carton (8 pce) 08711985477504
1121F3020003 88.9 xRc2 galvanized 2.77 kg 216x89x153 mm carton (6 pce) 08711985463538
1121F3020014 88.9 xRc2 galvanized 2.77 kg 216x89x153 mm carton (6 pce) 08711985480726
1121F4520014 114.3 xRc2 galvanized 4.23 kg 254x115x185 mm carton (3 pce) 08711985477511
item number size d1 DN1 l1 z1 d2 DN2 l2 z2 d3 DN3 l3 z3
1121F2910014 76.1 xRc1 galvanized 76.1 DN65 95 95 33.4 DN25 95 80 76.1 DN65 95 95
1121F2920014 76.1 xRc2 galvanized 76.1 DN65 95 95 60.3 DN50 95 76.1 DN65 95 95
1121F3010014 88.9 xRc1 galvanized 88.9 DN80 108 108 33.4 DN25 108 93 88.9 DN80 108 108
1121F3020003 88.9 xRc2 galvanized 88.9 DN80 108 108 60.3 DN50 108 88 88.9 DN80 108 108
1121F3020014 88.9 xRc2 galvanized 88.9 DN80 108 108 60.3 DN50 108 88 88.9 DN80 108 108
1121F4520014 114.3 xRc2 galvanized 114.3 DN100 127 127 60.3 DN50 127 107 114.3 DN100 127 127
see above for the diagram related to these dimensions
color silver
materials cast iron (ASTM A536 65-45-12)
finishing galvanised
manufacturer Shurjoint
shape T-piece (90Āŗ)
connection type groove (fitting), Rc - female thread gas conical (BSPT)
product group fittings (demountable)
ETIM class EC003025 Fitting with 3 connections
HS code 73071910
brand VSH
series Shurjoint
type 7121F
UNSPS 40174604
