group: 518E-VSH
potable water
heating
cooling
steam
compressed air
sprinkler
vacuum
fire protection
commercial building
industry
FM
IAPMO/ANSI/CAN Z1117
NSF/ANSI 372
NSF/ANSI 61
UL
ULc
item number
size
dimensions
weight
packaging
gtin
item number
size
Ø3/4”x1/2”
dimensions
81x33x33 mm
weight
0.11 kg
packaging
bag (10 pce)
gtin
08711985528367
item number
size
Ø1”x1/2”
dimensions
89x33x33 mm
weight
0.15 kg
packaging
bag (5 pce)
gtin
08711985528374
item number
size
Ø1”x3/4”
dimensions
86x38x38 mm
weight
0.15 kg
packaging
bag (5 pce)
gtin
08711985528381
item number
size
Ø1 1/2"x1/2"
dimensions
102x33x33 mm
weight
0.23 kg
packaging
bag (5 pce)
gtin
08711985528398
item number
size
Ø1 1/2”x3/4”
dimensions
99x38x38 mm
weight
0.24 kg
packaging
bag (1 pce)
gtin
08711985528404
item number
size
Ø1 1/2”x1”
dimensions
99x48x48 mm
weight
0.27 kg
packaging
bag (1 pce)
gtin
08711985528411
item number
size
Ø2"x1/2"
dimensions
114x33x33 mm
weight
0.32 kg
packaging
bag (1 pce)
gtin
08711985528428
item number
size
Ø2"x3/4"
dimensions
112x38x38 mm
weight
0.32 kg
packaging
bag (1 pce)
gtin
08711985528435
item number
size
Ø2"x1"
dimensions
111x48x48 mm
weight
0.37 kg
packaging
bag (1 pce)
gtin
08711985528442
item number
size
Ø2"x1 1/2"
dimensions
107x65x65 mm
weight
0.39 kg
packaging
bag (1 pce)
gtin
08711985528459
item number
size
d1
DN1
l1
z1
d2
DN2
l2
color
silver
materials
stainless steel (Stainless steel 316L (1.4404))
finishing
none
shape
straight, reducer
connection type
press, tube end
sealing
EPDM
product group
fittings
ETIM class
EC003024 Fitting with 2 connections
HS code
73072980
brand
VSH
series
SmartPress
type
518E
UNSPS
40173607
max operating pressure liquid
34.47 bar
min. medium temperature
-35 °C
max medium temperature
135 °C
peak medium temperature
150 °C
label
value
label
ETIM class
label
Material connection 1
value
Stainless steel
label
Material quality connection 1
value
Stainless steel 316 L (1.4404)
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Material connection 2
value
Stainless steel
label
Material quality connection 2
value
Stainless steel 316 L (1.4404)
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Straight
label
Model
value
1-part
label
Reducing
value
Yes
label
Eccentric
value
No
label
System specific
value
Yes
label
Connection 1
value
Press sleeve
label
Connection 2
value
Soldered end
label
Main colour fitting
value
Grey
label
Material sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
With buffer stud
value
Yes
label
High tensile strength
value
Yes
label
Medium temperature (continuous)
value
-35°C - 135°C
label
Medium temperature (continuous) (imperial)
value
-31°F - 275°F
label
Max. operating pressure at 20 °C
value
34.47bar
label
Max. operating pressure at 20 °C (imperial)
value
500psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With connection indicator
value
Yes
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
Yes
label
LPCB quality mark
value
No
label
ULC quality mark
value
Yes
label
UL quality mark
value
Yes
label
DIN-CERTCO certificate
value
No
label
VdS quality mark
value
No
label
With approval for TÜV
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
label
Type approval according to BBR/EKS
value
No
