SPS angle seat valve rising, with drain (2 x press)

group: 4626

The Type 4626 SPS valves with press connections have double O-ring seals with grease chamber for permanently smooth and low maintenance operation. The SPS press connections can be used for copper, galvanized steel and stainless steel pipes and can be pressed with M- or V-contour press jaws.

  • with rising handwheel
  • available with or without drain
  • with SPS press connection for copper, galvanized and stainless steel pipe
  • for M- or V-contour press jaws
  • also available with non-rising SEPP Servo Plus handle
  • also available as KFR valve (with integrated check valve)
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

potable water

potable water

heating

heating

segments

commercial building

commercial building

industry

industry

approvals

DVGW Wasser

DVGW Wasser

KIWA

KIWA

item number

size

dimensions

weight

packaging

gtin

item number

tw0037106

size

15 (DN15)

dimensions

142x78x116 mm

weight

0.41 kg

packaging

bag (1 pce)

gtin

04018422353587

item number

tw0037107

size

18 (DN20)

dimensions

155x82x121 mm

weight

0.56 kg

packaging

bag (1 pce)

gtin

04018422353594

item number

tw0037108

size

22 (DN20)

dimensions

155x82x121 mm

weight

0.54 kg

packaging

bag (1 pce)

gtin

04018422353600

item number

tw0037109

size

28 (DN25)

dimensions

175x85x146 mm

weight

0.78 kg

packaging

bag (1 pce)

gtin

04018422353617

item number

tw0037110

size

35 (DN32)

dimensions

208x92x175 mm

weight

1.15 kg

packaging

bag (1 pce)

gtin

04018422353624

item number

tw0037111

size

42 (DN40)

dimensions

229x104x192 mm

weight

1.62 kg

packaging

bag (1 pce)

gtin

04018422353631

item number

tw0211051

size

54 (DN50)

dimensions

283x110x235 mm

weight

2.26 kg

packaging

bag (1 pce)

gtin

04018422354355

item number

size

d1

DN1

l1

z1

d2

DN2

l2

z2

H1

H2

M

H

Y

V

U

a

item number

tw0037106

size

15 (DN15)

d1

15.0

DN1

DN12

l1

38

z1

12

d2

15.0

DN2

DN12

l2

72

z2

46

H1

20

H2

96

M

60

H

96

Y

14

V

96

U

15

a

41

item number

tw0037107

size

18 (DN20)

d1

18.0

DN1

DN15

l1

40

z1

11

d2

18.0

DN2

DN15

l2

84

z2

55

H1

18

H2

103

M

60

H

103

Y

14

V

110

U

15

a

41

item number

tw0037108

size

22 (DN20)

d1

22.0

DN1

DN20

l1

40

z1

11

d2

22.0

DN2

DN20

l2

84

z2

55

H1

18

H2

103

M

60

H

103

Y

14

V

110

U

15

a

41

item number

tw0037109

size

28 (DN25)

d1

28.0

DN1

DN25

l1

40

z1

11

d2

28.0

DN2

DN25

l2

91

z2

62

H1

23

H2

123

M

70

H

123

Y

19

V

127

U

19

a

41

item number

tw0037110

size

35 (DN32)

d1

35.0

DN1

DN32

l1

46

z1

14

d2

35.0

DN2

DN32

l2

102

z2

70

H1

25

H2

150

M

70

H

150

Y

19

V

163

U

22

a

41

item number

tw0037111

size

42 (DN40)

d1

42.0

DN1

DN40

l1

57

z1

21

d2

42.0

DN2

DN40

l2

121

z2

85

H1

29

H2

163

M

70

H

163

Y

25

V

169

U

22

a

41

item number

tw0211051

size

54 (DN50)

d1

54.0

DN1

DN50

l1

64

z1

18

d2

54.0

DN2

DN50

l2

144

z2

98

H1

38

H2

197

M

90

H

197

Y

25

V

225

U

24

a

41

technical drawing for product

characteristics

color

brass

materials

brass (CW625N (DZR))

finishing

none

shape

straight (0º)

connection type

press (M/V), G - male thread gas cylindrical (BSPP), G - female thread gas cylindrical (BSPP)

pressure rating (PN)

PN 16

sealing

EPDM

general

product group

valves (stop valves)

ETIM class

EC010058 Shut down valve (tap water)

HS code

84818019

brand

Seppelfricke

series

SEPP SPS®

type

4626

SCIP

797622a0-2bc2-4feb-b677-a9b24f611e83

technical

max operating pressure liquid

16 bar

max medium temperature

90 °C

peak medium temperature

90 °C

Kvs-value

image for 4626

image | png

4626

installation- & maintenance document | pdf

Seppelfricke_SPS_instruction-ML

image for Diagram

diagram | png

Diagram

certifications | pdf

Reach declaration

link to sheet | pdf

SDS-Seppelfricke_SPS_valves_EN

certifications | pdf

SPS-DVGW

certifications | pdf

SPS-KIWA

certifications | pdf

Schrägsitzventil_DVGW

label

value

label

Housing material

value

Brass

label

Housing material quality

value

Brass CW625N (CuZn35Pb1.5AlAs)

label

Connection 1

value

Press sleeve

label

With coupling connection 1

value

No

label

Connection 2

value

Press sleeve

label

With coupling connection 2

value

No

label

Contour code

value

M/V

label

Max. medium temperature (continuous)

value

90°C

label

Max. medium temperature (continuous) (imperial)

value

194°F

label

Surface protection

value

Untreated

label

With drain possibility (connection)

value

Yes

label

With drain valve

value

Yes

label

With position indicator

value

No

label

Spindle and/or hand wheel rising

value

Yes

label

Spindle angle

value

41°

label

Spindle angle (imperial)

value

1.61"
