Product Image for VSH Clamp 1-piece reducer

group: 201

The VSH Clamp 201 is a galvanized brass 1-piece reducer. Easy installation and high quality are the top priorities of the VSH Clamp product range.

simple installation with standard tools
quick connection technology allowing reassembly

read more

read less

if the download did not start automatically, click here

PDF generation failed, please try again later

heating

show all

show less

commercial building

industry

show all

show less

no approvals available

item number

size

dimensions

weight

packaging

gtin

item number

size

15x12

dimensions

18x18x21 mm

weight

0.01 kg

packaging

bag (10 pce)

gtin

08711985133554

item number

size

22x15

dimensions

25x25x23 mm

weight

0.03 kg

packaging

bag (10 pce)

gtin

08711985133578

item number

size

22x18

dimensions

25x25x23 mm

weight

0.03 kg

packaging

bag (10 pce)

gtin

08711985133592

item number

size

22x20

dimensions

24x24x19 mm

weight

0.01 kg

packaging

bag (10 pce)

gtin

08711985133615

item number

size

28x15

dimensions

31x31x24 mm

weight

0.07 kg

packaging

bag (5 pce)

gtin

08711985133639

item number

size

28x22

dimensions

31x31x24 mm

weight

0.05 kg

packaging

bag (5 pce)

gtin

08711985133653

item number

size

35x22

dimensions

38x38x30 mm

weight

0.11 kg

packaging

bag (1 pce)

gtin

08711985133677

item number

size

35x28

dimensions

38x38x30 mm

weight

0.08 kg

packaging

bag (1 pce)

gtin

08711985133691

item number

size

d1

DN1

l1

d2

DN2

item number

size

15x12

d1

15.0

DN1

DN12

l1

18

d2

12.0

DN2

DN10

item number

size

22x15

d1

22.0

DN1

DN20

l1

25

d2

15.0

DN2

DN12

item number

size

22x18

d1

22.0

DN1

DN20

l1

25

d2

18.0

DN2

DN15

item number

size

22x20

d1

22.0

DN1

DN20

l1

24

d2

20.0

DN2

DN15

item number

size

28x15

d1

28.0

DN1

DN25

l1

31

d2

15.0

DN2

DN12

item number

size

28x22

d1

28.0

DN1

DN25

l1

31

d2

22.0

DN2

DN20

item number

size

35x22

d1

35.0

DN1

DN32

l1

38

d2

22.0

DN2

DN20

item number

size

35x28

d1

35.0

DN1

DN32

l1

38

d2

28.0

DN2

DN25

characteristics

color

silver

materials

brass (CW602N (DZR))

finishing

galvanised

shape

straight, reducer

connection type

clamp

general

product group

fittings (demountable)

ETIM class

EC010170 Compression ring reducing set

HS code

74122000

brand

VSH

series

Clamp

type

201

UNSPS

40173601

SCIP

98ab3390-1a8e-4560-943d-8a0d9c101b3e

technical

max operating pressure liquid

6 bar

max medium temperature

90 °C

peak medium temperature

120 °C

image for 201

image | png

201

image for Diagram

diagram | png

Diagram

link to sheet | pdf

MSDS_VSH_Klem

certifications | pdf

Reach declaration

certifications | pdf

TM65 Embodied Carbon Declaration

label

value

label

ETIM class

value

EC010170 Compression ring reducing set

label

Material

value

Brass

item number

carbon footprint (A-C) embodied carbon

data source

item number

carbon footprint (A-C) embodied carbon

0.1kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.2kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.16kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.11kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.37kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.27kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.56kgCO2e

data source

TM65

item number

carbon footprint (A-C) embodied carbon

0.45kgCO2e

data source

TM65
