SEPP DIN-Basis KFR-valve headpart

code

size

dimensions

weight

packaging

gtin

code

0048980

size

G1/2" (DN15)

dimensions

75x60x60 mm

weight

0.13 kg

packaging

bag (1 pce)

gtin

04018422282870

code

0048982

size

G3/4" (DN20)

dimensions

81x60x60 mm

weight

0.17 kg

packaging

bag (1 pce)

gtin

04018422282887

code

0048984

size

G1" (DN25)

dimensions

95x70x70 mm

weight

0.29 kg

packaging

bag (1 pce)

gtin

04018422282894

code

0048985

size

G1 1/4" (DN32)

dimensions

120x70x70 mm

weight

0.49 kg

packaging

bag (1 pce)

gtin

04018422282900

code

0048987

size

G1 1/2" (DN40)

dimensions

123x90x90 mm

weight

0.55 kg

packaging

bag (1 pce)

gtin

04018422282917

code

0048989

size

G2" (DN50)

dimensions

162x90x90 mm

weight

0.86 kg

packaging

bag (1 pce)

gtin

04018422282924

code

size

DN1

l1

slw1

M

Y

V

U

D1

code

0048980

size

G1/2" (DN15)

DN1

1/2" (DN15)

l1

35

slw1

17

M

60

Y

14

V

97

U

36

D1

16

code

0048982

size

G3/4" (DN20)

DN1

3/4" (DN20)

l1

43

slw1

17

M

60

Y

14

V

111

U

38

D1

22

code

0048984

size

G1" (DN25)

DN1

1" (DN25)

l1

52

slw1

22

M

70

Y

19

V

129

U

46

D1

28

code

0048985

size

G1 1/4" (DN32)

DN1

1 1/4" (DN32)

l1

63

slw1

27

M

70

Y

19

V

165

U

52

D1

35

code

0048987

size

G1 1/2" (DN40)

DN1

1 1/2" (DN40)

l1

72

slw1

27

M

90

Y

23

V

173

U

56

D1

41

code

0048989

size

G2" (DN50)

DN1

2" (DN50)

l1

92

slw1

32

M

90

Y

23

V

232

U

68

D1

53

product info

item

SEPP DIN-Basis KFR-valve headpart

item number with gtin

1999

manufacturer

Aalberts integrated piping systems B.V. (VSH)

weight

0.86 kg

dimensions

162x90x90 mm

characteristics

color

brass, green

materials

brass (CW617N)

finishing

none

shape

straight

connection type

G - male thread gas cylindrical (BSPP)

pressure rating (PN)

PN 16

sealing

EPDM

technical

max operating pressure liquid

16 bar

max medium temperature

90 °C

peak medium temperature

90 °C

general

product group

valves (accessories (valves), stop valves, check valves)

ETIM class

EC011657 Accessories/spare parts for globe valve

HS code

84819000

brand

Seppelfricke

series

SEPP DIN-Basis

type

1999

SCIP

595b237a-cb3d-4f91-8731-a4c832a4905b

image | jpg

1999

diagram | png

Diagram

certifications | pdf

Reach declaration

certifications | pdf

SEPP_ UA_Gebaeudearmaturen

certifications | pdf

SEPP_UA_Gebaeudearmaturen_1Nf
