SEPP DIN-Gerade right angle valve with drain (2 x female thread)

SEPP DIN-Gerade right angle valve with drain (2 x female thread)

group: 1206

The SEPP DIN 1206 stop valve is a brass stop valve with angled spindle according to DIN EN 1213.
The stop valve is fitted with female thread, a rising stem with double o-ring seal and a robust rotary grip. The stop valve is easy to operate and requires little maintenance.
The SEPP DIN 1206 stop valve is equiped with a drain valve. SEPP DIN models are also available without draining connection: Type SEPP DIN 1201

  • double o-ring seal
  • easy to operate
  • low maintenance
  • with drain valve



applications

potable water

potable water

show all
show less

solutions

building installations

building installations

industry

industry

show all
show less

approvals

no approvals available

item number size weight dimensions packaging gtin
0000219 Rp1/2" (DN15) 0.26 kg 64x60x73 mm carton (1 pce) 04018422001013
0000220 Rp3/4" (DN20) 0.41 kg 93x60x74 mm carton (1 pce) 04018422001020
0000221 Rp1" (DN25) 0.78 kg 113x70x92 mm carton (1 pce) 04018422001037
item number size DN1 l1 z1 slw1 DN2 l2 z2 slw2 M Y V a
0000219 Rp1/2" (DN15) 1/2" (DN15) 30 17 25 1/2" (DN15) 34 21 25 60 14 55
0000220 Rp3/4" (DN20) 3/4" (DN20) 35 21 32 3/4" (DN20) 39 24 32 60 14 75
0000221 Rp1" (DN25) 1" (DN25) 45 29 41 1" (DN25) 47 30 41 70 19 90 90
drawing for product
color brass, green
materials brass (CW617N)
finishing none
manufacturer Seppelfricke
shape straight (0º)
connection type Rp - female thread cylindrical (BSPT)
pressure rating (PN) PN 10
sealing EPDM
product group valves (stop valve)
ETIM class EC010058 Shut down valve (tap water)
HS code 84818079
brand Seppelfricke
series SEPP DIN-Gerade
type 1206
UNSPS 40141611
SCIP 62ae05cb-5d58-4e86-a09a-90069f6f35a4
label value
ETIM class EC010058 Shut down valve (tap water)
Housing material Brass
Housing material quality CuZn40Pb2 (CW617N)
Connection 1 Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
With coupling connection 1 No
Connection 2 Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
With coupling connection 2 No
Max. medium temperature (continuous) 90°C
Max. medium temperature (continuous) (imperial) 194°F
Surface protection Untreated
With drain possibility (connection) Yes
With drain valve Yes
With position indicator No
Spindle and/or hand wheel rising Yes

accessories

item number description
0001452 Seppelfricke SEPP Servo upper part rising spindle G1/2" (DN15)
0001453 Seppelfricke SEPP Servo upper part rising spindle G3/4" (DN20)
0001454 Seppelfricke SEPP Servo upper part rising spindle G1" (DN25)
0033121 Seppelfricke SEPP Servo hand wheel DN15-20 SW6,5 x D60
0033062 Seppelfricke SEPP Servo hand wheel DN25-32 SW8,0 x D70
0534463 Seppelfricke SEPP Safe sampling valve with stainless steel pipe MM G1/4" x G3/8" (DN8)
0033464 Seppelfricke SEPP Servo hand wheel DN25-32 SW8,0 x D90
0018905 Seppelfricke SEPP DIN-Basis drain valve M G1/4" (DN8)
0029070 Seppelfricke SEPP DIN-Basis drain valve set G1/4" (DN8)
0022828 Seppelfricke SEPP DIN-Basis plug M G1/4" (DN8)
0025349 Seppelfricke SEPP DIN-Basis drain valve set G1/4" (DN8)
0214284 Seppelfricke SEPP Fix extension MF G1/4" (DN8)
