VSH Super Gas Belgium straight connector (compression x male thread)

group: G1202

The VSH Super G1202 is a straight connector with a compression and a male thread end. This is a special Gas fitting, designed for Belgium only. VSH Super provides a large assortment of fittings for every application, designed for optimum installation convenience. Easy installation and high quality are the top priorities of the VSH Super product range.

  • special Gas fitting for the Belgium market
  • simple installation with standard tools
  • quick connection technology allowing reassembly
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

natural gas

natural gas

hydrogen (H2)

hydrogen (H2)

segments

residential

residential

commercial building

commercial building

industry

industry

approvals

ARGB-KVBG

ARGB-KVBG

GASTEC

GASTEC

Gastec-H2-ready

Gastec-H2-ready

item number

size

dimensions

weight

packaging

gtin

item number

0879538

size

12xR3/8"

dimensions

45x25x25 mm

weight

0.06 kg

packaging

bag (25 pce)

gtin

08711985148206

item number

0879351

size

12xR1/2"

dimensions

47x25x25 mm

weight

0.08 kg

packaging

bag (10 pce)

gtin

08711985334241

item number

0879252

size

15xR3/8"

dimensions

49x28x28 mm

weight

0.08 kg

packaging

bag (10 pce)

gtin

08711985147865

item number

0879362

size

15xR1/2"

dimensions

54x28x28 mm

weight

0.09 kg

packaging

bag (10 pce)

gtin

08711985148008

item number

0879065

size

15xR3/4"

dimensions

53x32x32 mm

weight

0.1 kg

packaging

bag (25 pce)

gtin

08711985147681

item number

0876810

size

18xR1/2"

dimensions

58x32x32 mm

weight

0.11 kg

packaging

bag (25 pce)

gtin

08711985147261

item number

0879098

size

18xR3/4"

dimensions

57x32x32 mm

weight

0.13 kg

packaging

bag (25 pce)

gtin

08711985147704

item number

0879373

size

22xR3/4"

dimensions

61x38x38 mm

weight

0.15 kg

packaging

bag (5 pce)

gtin

08711985148022

item number

0879384

size

22xR1"

dimensions

66x42x42 mm

weight

0.2 kg

packaging

bag (5 pce)

gtin

08711985148046

item number

0879395

size

28xR1"

dimensions

71x46x46 mm

weight

0.24 kg

packaging

bag (5 pce)

gtin

08711985148060

item number

size

d1

DN1

l1

slw1

d2

DN2

l2

slw0

h

item number

0879538

size

12xR3/8"

d1

12.0

DN1

DN10

l1

27

slw1

21

d2

17.2

DN2

3/8" (DN10)

l2

18

slw0

17

h

5.5

item number

0879351

size

12xR1/2"

d1

12.0

DN1

DN10

l1

27

slw1

21

d2

21.3

DN2

1/2" (DN15)

l2

20

slw0

22

h

6.5

item number

0879252

size

15xR3/8"

d1

15.0

DN1

DN12

l1

31

slw1

24

d2

17.2

DN2

3/8" (DN10)

l2

18

slw0

22

h

6.5

item number

0879362

size

15xR1/2"

d1

15.0

DN1

DN12

l1

31

slw1

24

d2

21.3

DN2

1/2" (DN15)

l2

23

slw0

22

h

7

item number

0879065

size

15xR3/4"

d1

15.0

DN1

DN12

l1

31

slw1

24

d2

26.9

DN2

3/4" (DN20)

l2

22

slw0

27

h

5.6

item number

0876810

size

18xR1/2"

d1

18.0

DN1

DN15

l1

35

slw1

27

d2

21.3

DN2

1/2" (DN15)

l2

23

slw0

24

h

6.5

item number

0879098

size

18xR3/4"

d1

18.0

DN1

DN15

l1

34

slw1

27

d2

26.9

DN2

3/4" (DN20)

l2

23

slw0

27

h

5.5

item number

0879373

size

22xR3/4"

d1

22.0

DN1

DN20

l1

38

slw1

32

d2

26.9

DN2

3/4" (DN20)

l2

23

slw0

30

h

7.5

item number

0879384

size

22xR1"

d1

22.0

DN1

DN20

l1

38

slw1

32

d2

33.7

DN2

1" (DN25)

l2

28

slw0

36

h

6.5

item number

0879395

size

28xR1"

d1

28.0

DN1

DN25

l1

42

slw1

39

d2

33.7

DN2

1" (DN25)

l2

29

slw0

36

h

7.5

technical drawing for product

characteristics

color

brass

materials

brass (CW617N)

finishing

none

shape

straight, reducer

connection type

compression

sealing

Brass

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

74122000

brand

VSH

series

Super Gas Belgium

type

G1202

SCIP

1e5d1bf2-d72d-4b8f-ba91-73f637c5ac6d

technical

min. medium temperature

-20 °C

max medium temperature

60 °C

image for G1202

image | png

G1202

installation- & maintenance document | pdf

VSH_Super_Knel_instructie_NL

image for Diagram

diagram | png

Diagram

certifications | pdf

EPD VSH Super Brass

link to sheet | pdf

MSDS_VSH_Super

certifications | pdf

Reach declaration

certifications | pdf

VSH Super Gas 12-28mm ARGB-KVBG

certifications | pdf

VSH Super Gas GASTEC QA 10-54mm

installation- & maintenance document | pdf

VSH Super Gas instructions

certifications | pdf

VSH Super Gastec H2

label

value

label

Material connection 1

value

Brass

label

Material quality connection 1

value

CuZn40Pb2 (CW617N)

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Brass

label

Material quality connection 2

value

CuZn40Pb2 (CW617N)

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Straight

label

Model

value

1-part

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Compression ring

label

Main colour fitting

value

Brass

label

Material sealing

value

Brass

label

With buffer stud

value

Yes

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-20°C - 60°C

label

Medium temperature (continuous) (imperial)

value

-4°F - 140°F

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

KOMO certified

value

No

item number

carbon footprint (A1-A3) cradle-to-gate

carbon footprint (A-C) embodied carbon

carbon footprint (A-D) cradle-to-cradle

data source

item number

0879538

carbon footprint (A1-A3) cradle-to-gate

0.36kgCO2e

carbon footprint (A-C) embodied carbon

0.26kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.24kgCO2e

data source

EPD

item number

0879351

carbon footprint (A1-A3) cradle-to-gate

0.5kgCO2e

carbon footprint (A-C) embodied carbon

0.37kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.34kgCO2e

data source

EPD

item number

0879252

carbon footprint (A1-A3) cradle-to-gate

0.5kgCO2e

carbon footprint (A-C) embodied carbon

0.37kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.33kgCO2e

data source

EPD

item number

0879362

carbon footprint (A1-A3) cradle-to-gate

0.55kgCO2e

carbon footprint (A-C) embodied carbon

0.41kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.37kgCO2e

data source

EPD

item number

0879065

carbon footprint (A1-A3) cradle-to-gate

0.64kgCO2e

carbon footprint (A-C) embodied carbon

0.47kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.43kgCO2e

data source

EPD

item number

0876810

carbon footprint (A1-A3) cradle-to-gate

0.67kgCO2e

carbon footprint (A-C) embodied carbon

0.5kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.45kgCO2e

data source

EPD

item number

0879098

carbon footprint (A1-A3) cradle-to-gate

0.8kgCO2e

carbon footprint (A-C) embodied carbon

0.59kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.54kgCO2e

data source

EPD

item number

0879373

carbon footprint (A1-A3) cradle-to-gate

0.95kgCO2e

carbon footprint (A-C) embodied carbon

0.71kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.64kgCO2e

data source

EPD

item number

0879384

carbon footprint (A1-A3) cradle-to-gate

1.28kgCO2e

carbon footprint (A-C) embodied carbon

0.95kgCO2e

carbon footprint (A-D) cradle-to-cradle

0.86kgCO2e

data source

EPD

item number

0879395

carbon footprint (A1-A3) cradle-to-gate

1.51kgCO2e

carbon footprint (A-C) embodied carbon

1.12kgCO2e

carbon footprint (A-D) cradle-to-cradle

1.02kgCO2e

data source

EPD
