VSH SudoPress Copper crossover (2 x press)

group: SP5085V

The VSH SudoPress SP5085V is a crossover with 2 press ends. Idead for crossing pipes in the same plane. By using VSH SudoPress in your piping installation you can install in a quick, easy and clean way. VSH SudoPress provides a piping system that can be used in the most diverse situations.

  • double safety through Visu-Control® and Leak Before Pressed function
  • provided with all relevant approvals
  • clear identification on fitting of material and dimension
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

potable water

potable water

heating

heating

cooling

cooling

compressed air

compressed air

solar energy

solar energy

vacuum

vacuum

segments

commercial building

commercial building

industry

industry

shipbuilding

shipbuilding

approvals

ACS

ACS

DVGW Wasser

DVGW Wasser

QB (CSTBat)

QB (CSTBat)

RISE

RISE

TSU

TSU

WRAS

WRAS

item number

size

d1

DN1

l1

z1

d2

DN2

l2

z2

item number

6671456

size

15

d1

15.0

DN1

DN12

l1

69

z1

47

d2

15.0

DN2

DN12

l2

69

z2

47

item number

6671467

size

18

d1

18.0

DN1

DN15

l1

73

z1

51

d2

18.0

DN2

DN15

l2

73

z2

51

item number

6671478

size

22

d1

22.0

DN1

DN20

l1

81

z1

58

d2

22.0

DN2

DN20

l2

81

z2

58

technical drawing for product

characteristics

color

copper

materials

copper (CW024A (UNS C12200))

finishing

none

shape

Jump (0º)

connection type

press (V)

sealing

EPDM

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

74122000

brand

VSH

series

SudoPress Copper

type

SP5085V

UNSPS

40172807

label

value

label

Material connection 1

value

Copper

label

Material quality connection 1

value

Cu-DHP (CW024A)

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Copper

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Offset

label

Model

value

1-part

label

Bend angle

value

label

Reducing

value

No

label

Eccentric

value

No

label

System specific

value

Yes

label

Connection 1

value

Press sleeve

label

Contour code connection 1

value

V

label

Connection 2

value

Press sleeve

label

Contour code connection 2

value

V

label

Main colour fitting

value

Copper

label

Flange compression class (PN)

value

PN 16

label

Material sealing

value

Ethylene-propylene diene monomer rubber (EPDM)

label

With buffer stud

value

Yes

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-20°C - 110°C

label

Medium temperature (continuous) (imperial)

value

-4°F - 230°F

label

Max. operating pressure at 20 °C

value

16bar

label

Max. operating pressure at 20 °C (imperial)

value

232.06psi

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

Yes

label

With drain valve

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

VdS quality mark

value

No

label

DVGW quality mark for gas

value

No

label

DVGW quality mark for water

value

Yes

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No
