group: R2742G
The VSH XPress R2742G is a flat seal NBR, applicable for Gas. This flat seal is part of the VSH XPress stainless steel gas system. The yellow colour of the o-ring ensures a clear identification of the system.
natural gas
industry
commercial building
DVGW Gas
ÖVGW Gas
SVGW Gas
ARGB-KVBG
BSI Kitemark
code
size
dimensions
weight
packaging
gtin
code
size
22 DN20
dimensions
30x30x2 mm
weight
0 kg
packaging
bag (20 pce)
gtin
08711985282078
code
size
28 DN25
dimensions
39x39x2 mm
weight
0 kg
packaging
bag (20 pce)
gtin
08711985282085
code
size
35 DN32
dimensions
45x45x2 mm
weight
0 kg
packaging
bag (20 pce)
gtin
08711985282092
code
size
42 DN40
dimensions
51x51x2 mm
weight
0 kg
packaging
bag (20 pce)
gtin
08711985282108
code
size
54 DN50
dimensions
67x67x3 mm
weight
0 kg
packaging
bag (20 pce)
gtin
08711985282115
item
VSH XPress Stainless Gas flat seal NBR
item number with gtin
R2742G
manufacturer
Aalberts integrated piping systems B.V. (VSH)
weight
0 kg
dimensions
67x67x3 mm
color
yellow
materials
rubber (NBR (Nitril))
finishing
none
shape
round
connection type
press (M)
pressure rating (PN)
PN 5
sealing
HNBR
min. medium temperature
-20 °C
max medium temperature
70 °C
peak medium temperature
70 °C
product group
fittingen (accessories (fittings))
ETIM class
EC001181 Sealing ring, flatHS code
40169300
brand
VSH
series
XPress Stainless Gas
type
R2742G
UNSPS
31401501
label
value
label
etim-class
label
Material
value
Rubber
label
Material quality
value
NBR (nitrile rubber)
label
Ring model
value
Massive
label
With washer
value
No
code
