VSH XPress Stainless Gas slip coupling (2 x press)

group: R2703G

The VSH XPress R2703G is a stainless steel slip coupling with 2 press ends, applicable for Gas. Ideal for applications where high levels of hydrogen sulphide make copper an unsuitable material choice. The yellow O-ring and prominent marking on the exterior of this fitting ensure a clear identification of the system.

  • safer installation due to no naked flames or heat required
  • provided with all relevant approvals
  • clear identification on fitting of material and dimension
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

natural gas

natural gas

segments

commercial building

commercial building

industry

industry

approvals

ARGB-KVBG

ARGB-KVBG

BSI Kitemark

BSI Kitemark

DVGW Gas

DVGW Gas

ÖVGW Gas

ÖVGW Gas

SVGW Gas

SVGW Gas

item number

size

d1

DN1

l1

es1

d2

DN2

l2

es2

item number

6210105

size

15

d1

15.0

DN1

DN12

l1

36

es1

20

d2

15.0

DN2

DN12

l2

36

es2

20

item number

6210116

size

18

d1

18.0

DN1

DN15

l1

39

es1

20

d2

18.0

DN2

DN15

l2

39

es2

20

item number

6210127

size

22

d1

22.0

DN1

DN20

l1

41

es1

21

d2

22.0

DN2

DN20

l2

41

es2

21

item number

6210138

size

28

d1

28.0

DN1

DN25

l1

45

es1

23

d2

28.0

DN2

DN25

l2

45

es2

23

item number

6210149

size

35

d1

35.0

DN1

DN32

l1

50

es1

26

d2

35.0

DN2

DN32

l2

50

es2

26

item number

6210151

size

42

d1

42.0

DN1

DN40

l1

58

es1

30

d2

42.0

DN2

DN40

l2

58

es2

30

item number

6210160

size

54

d1

54.0

DN1

DN50

l1

70

es1

35

d2

54.0

DN2

DN50

l2

70

es2

35

technical drawing for product

characteristics

color

silver

materials

stainless steel (Stainless steel 316L (1.4404))

finishing

none

shape

straight

connection type

press (M)

sealing

HNBR

general

product group

fittings

ETIM class

EC003024 Fitting with 2 connections

HS code

73072980

brand

VSH

series

XPress Stainless Gas

type

R2703G

technical

min. medium temperature

-20 °C

max medium temperature

70 °C

peak medium temperature

70 °C

image for R2703G

image | png

R2703G

image for Diagram

diagram | png

Diagram

certifications | pdf

VSH XPress Stainless DVGW Gas

certifications | pdf

VSH XPress Stainless Gas ARGB-KVBG

certifications | pdf

VSH XPress Stainless Gas BSI

certifications | pdf

VSH XPress Stainless OVGW Gas

certifications | pdf

VSH XPress Stainless SVGW Gas

installation- & maintenance document | pdf

VSH XPress installation instructions

label

value

label

Material connection 1

value

Stainless steel

label

Material quality connection 1

value

Stainless steel 316 L (1.4404)

label

Surface protection connection 1

value

Untreated

label

Surface treatment connection 1

value

Untreated

label

Material connection 2

value

Stainless steel

label

Material quality connection 2

value

Stainless steel 316 L (1.4404)

label

Surface protection connection 2

value

Untreated

label

Surface treatment connection 2

value

Untreated

label

Shape

value

Straight

label

Model

value

1-part

label

Reducing

value

No

label

Eccentric

value

No

label

System specific

value

Yes

label

Wall thickness, connection 1

value

1.5mm

label

Wall thickness, connection 1 (imperial)

value

0.06"

label

Connection 1

value

Press sleeve

label

Contour code connection 1

value

M

label

Wall thickness, connection 2

value

1.5mm

label

Wall thickness, connection 2 (imperial)

value

0.06"

label

Connection 2

value

Press sleeve

label

Contour code connection 2

value

M

label

Main colour fitting

value

Grey

label

Material sealing

value

Hydrogenated acrylonitrile butadiene rubber (HNBR)

label

With buffer stud

value

No

label

High tensile strength

value

Yes

label

Medium temperature (continuous)

value

-20°C - 70°C

label

Medium temperature (continuous) (imperial)

value

-4°F - 158°F

label

With thermal insulation

value

No

label

With sealing rings/gaskets

value

No

label

Capped

value

No

label

With connection indicator

value

No

label

With drain valve

value

No

label

With de-aerator

value

No

label

FM quality mark

value

No

label

LPCB quality mark

value

No

label

ULC quality mark

value

No

label

UL quality mark

value

No

label

DIN-CERTCO certificate

value

No

label

VdS quality mark

value

No

label

With approval for TÜV

value

No

label

DVGW quality mark for gas

value

Yes

label

DVGW quality mark for water

value

No

label

Certified according to NF 545

value

No

label

KIWA certified

value

No

label

Gastec QA mark

value

No

label

KOMO certified

value

No

label

Gastec QA - AR 214 (H2)

value

No

label

Type approval according to BBR/EKS

value

No

item number

carbon footprint (A-C) embodied carbon

data source

item number

6210105

carbon footprint (A-C) embodied carbon

0.37kgCO2e

data source

TM65

item number

6210127

carbon footprint (A-C) embodied carbon

0.63kgCO2e

data source

TM65

item number

6210138

carbon footprint (A-C) embodied carbon

0.84kgCO2e

data source

TM65

item number

6210149

carbon footprint (A-C) embodied carbon

1.1kgCO2e

data source

TM65

item number

6210151

carbon footprint (A-C) embodied carbon

1.59kgCO2e

data source

TM65

item number

6210160

carbon footprint (A-C) embodied carbon

2.33kgCO2e

data source

TM65
