C9401G
VSH PowerPress Gas® C9401G is a straight coupling designed for thick wall steel pipe. By using VSH PowerPress Gas® system installation times are reduced significantly and a clean working environment is assured. The range consists of DW-profile press fittings and valves in sizes ½" up to and including 2".
applications
solutions
approvals
item number | size | weight | dimensions | packaging | gtin |
---|---|---|---|---|---|
123459094 | 1/2" | 0.11 kg | 68x32x32 mm | bag (10 pce) | 08711985499667 |
123459095 | 3/4" | 0.14 kg | 74x38x38 mm | bag (10 pce) | 08711985499674 |
123459096 | 1" | 0.22 kg | 84x46x46 mm | bag (5 pce) | 08711985499681 |
123459097 | 1 1/4" | 0.35 kg | 112x56x56 mm | bag (1 pce) | 08711985499698 |
123459098 | 1 1/2" | 0.48 kg | 115x62x62 mm | bag (1 pce) | 08711985499704 |
123459099 | 2" | 0.64 kg | 122x74x74 mm | bag (1 pce) | 08711985499711 |
item number | size | d1 | DN1 | l1 | z1 | d2 | DN2 | l2 | z2 |
---|---|---|---|---|---|---|---|---|---|
123459094 | 1/2" | 21.3 | DN15 | 34 | 6 | 21.3 | DN15 | 34 | 6 |
123459095 | 3/4" | 26.9 | DN20 | 37 | 6 | 26.9 | DN20 | 37 | 6 |
123459096 | 1" | 33.7 | DN25 | 42 | 6 | 33.7 | DN25 | 42 | 6 |
123459097 | 1 1/4" | 42.4 | DN32 | 56 | 8 | 42.4 | DN32 | 56 | 8 |
123459098 | 1 1/2" | 48.3 | DN40 | 57 | 8 | 48.3 | DN40 | 57 | 8 |
123459099 | 2" | 60.3 | DN50 | 61 | 8 | 60.3 | DN50 | 61 | 8 |
color | grey |
---|---|
materials | steel (St 35 (1.0308)) |
finishing | zinc-nickel plated |
manufacturer | Aalberts integrated piping systems B.V. (VSH) |
shape | straight |
connection type | press (DW) |
sealing | HNBR |
product group | fittings |
---|---|
ETIM class | EC003024 Fitting with 2 connections |
HS code | 73079980 |
brand | VSH |
series | PowerPress Gas |
type | C9401G |
UNSPS | 40172602 |
Diagram diagram |
png | download |
VSH PowerPress DVGW Gas certifications |
download | |
VSH PowerPress Gas BSI certifications |
download | |
VSH PowerPress Gas Gastec certifications |
download | |
VSH PowerPress Gas Gastec H2 certifications |
download | |
VSH PowerPress Gas instructions installation- & maintenance document |
download | |
C9401G image |
png | download |
label | value |
---|---|
ETIM class | EC003024 Fitting with 2 connections |
Material connection 1 | Steel |
Material quality connection 1 | St 35 (1.0308) |
Surface protection connection 1 | Zinc/nickel |
Material connection 2 | Steel |
Material quality connection 2 | St 35 (1.0308) |
Surface protection connection 2 | Zinc/nickel |
Shape | Straight |
Model | 1-part |
Reducing | No |
Eccentric | No |
System specific | Yes |
Connection 1 | Press sleeve |
Contour code connection 1 | DW |
Connection 2 | Press sleeve |
Contour code connection 2 | DW |
Main colour fitting | Grey |
Material sealing | Hydrogenated acrylonitrile butadiene rubber (HNBR) |
With buffer stud | Yes |
High tensile strength | Yes |
Medium temperature (continuous) | -20°C - 70°C |
Medium temperature (continuous) (imperial) | -4°F - 158°F |
With thermal insulation | No |
With sealing rings/gaskets | No |
Capped | Yes |
With connection indicator | Yes |
With drain valve | No |
With de-aerator | No |
FM quality mark | No |
LPCB quality mark | No |
ULC quality mark | No |
UL quality mark | No |
DIN-CERTCO certificate | No |
VdS quality mark | No |
With approval for TĆV | No |
DVGW quality mark for gas | Yes |
DVGW quality mark for water | No |
Certified according to NF 545 | No |
KIWA certified | No |
Gastec QA mark | Yes |
KOMO certified | No |
Type approval according to BBR/EKS | No |
item number | description | |
---|---|---|
PWR9401744 | VSH PowerPress insertion depth marker 1/2"-2" |
